1. Overview

2. Parameters and Technical Specifications

3. Product Features

• High Resolution: Equipped with 20-bit resolution, the module delivers ultra-high-precision weighing measurements, making it ideal for industries with stringent accuracy requirements.
• High-Speed Sampling: Supports 50 measurements per second, enabling reliable performance for dynamic weighing and flow metering applications that demand real-time data acquisition.
• Industrial-Grade Compatibility: Engineered to meet harsh industrial environment standards, it supports the Modbus/TCP protocol for seamless integration into existing industrial networks, reducing deployment complexity.
• Space-Saving Design: Features a compact DIN rail mounting structure, perfect for cabinet installation without occupying extra chassis space, optimizing cabinet layout and space utilization.

_______________________________________________________________________________________________________

4. Structure and Components

• Input Terminal Block: Used to connect 4-20mA analog signal sources, such as load cells and pressure sensors, ensuring stable signal transmission.
• Communication Module: Built-in Ethernet port that fully supports the Modbus/TCP communication protocol, facilitating efficient data interaction with upper-level control systems and PLCs.
• Power Module: Directly draws 24V DC power from the PLC main unit, eliminating the need for an independent power supply and simplifying on-site wiring.
• Signal Processing Circuit: Responsible for converting analog signals to digital signals, and performing professional signal conditioning including amplification and filtering to enhance signal stability and accuracy.

_______________________________________________________________________________________________________

5. Application Fields

• Industrial Weighing: Widely used in silo weighing, raw material proportioning, batching control and other scenarios that require high-precision weighing to ensure production accuracy and material management efficiency.
• Flow Metering: Used in conjunction with flow transmitters for accurate metering of liquid or gas flow, supporting process monitoring and data statistics in industrial production.
• Process Control: Applied to industrial processes that require analog-to-digital conversion for precise control, covering manufacturing, chemical, food processing and other automated production links.

_______________________________________________________________________________________________________

6. Installation and Maintenance

• Installation Method: Standard DIN rail mounting, simply slide the module into the cabinet DIN rail and secure it, enabling quick and hassle-free installation without complex tools.
• Wiring: Connect the module to the PLC’s 24V DC power supply, link the Ethernet port to the industrial network, and attach analog input terminals to corresponding sensors to complete the wiring setup.
• Maintenance: The module is designed with no moving parts, so routine maintenance is minimal. Core maintenance tasks include dust and moisture prevention, and regular inspection of cable connections to ensure tight contact and stable signal transmission.
