Product Type:Analog Input Module

Model Number:TM2AMI2HTN

Module Designation:Schneider

Input Channels:2

Input Level:High

Input Type:Current 4…20 mA, Voltage 0…10 V

Supply Voltage:External 24 V DC

Voltage Limits:20.4…28.8 V DC

Electrical Connection:Removable Screw Terminal Block

Current Consumption:40 mA @ 24 V DC External, 50 mA @ 5 V DC Internal

Insulation Voltage:2000 V between terminals/mounting rails

Weight:0.43 kg

    Crafted with precision and reliability, the Schneider TM2AMI2HTN analog input module seamlessly integrates into your industrial control system, ensuring accurate signal acquisition from sensors.

    Featuring dual high-level analog inputs, this module supports both current (4…20 mA) and voltage (0…10 V) signals, providing flexibility for various sensor configurations.

    Equipped with an external 24 V DC supply, the module ensures stable operation across diverse industrial environments, with voltage limits set to protect against overloads.

    The removable screw terminal block facilitates easy installation and maintenance, allowing for quick connection and disconnection of input sources without compromising safety or performance.

    With its robust insulation voltage of 2000 V between terminals and mounting rails, the Schneider TM2AMI2HTN ensures isolation from electrical disturbances, safeguarding against potential damage or malfunctions.

    Engineered for efficiency, this module consumes minimal power, reducing operational costs and environmental impact without compromising on functionality.
