Schneider TM221ME16R
1. Overview
The TM221ME16R is a highly integrated logic controller with on-site input/output (I/O) functions and communication expansion capabilities. It is mainly used in the fields of mechanical automation, building facility management and process control, and is suitable for application scenarios with strict requirements on volume and power consumption.
______________________________________________________________________________________________________________
2. Core Parameters
|
Parameters
|
Specifications
|
|---|---|
|
Input/Output Points
|
16 points I/O (including digital input/output)
|
|
Relay Output
|
8 channels of relays (NO/NC)
|
|
Communication Interface
|
1 channel RS485 (for Modbus RTU) + 1 channel RJ45 Ethernet (for Modbus TCP)
|
|
Power Supply
|
DC24V
|
|
Operating Temperature
|
-10℃ – +60℃
|
|
Operating Humidity
|
5% – 95% (no condensation)
|
|
Certifications
|
CE, ROHS, REACH (compliant with EU environmental protection directives)
|
______________________________________________________________________________________________________________
3. Product Features
- Compact Integration: Adopts a book-type design with a sturdy and durable shell, built-in power module, small size and easy installation.
- Multi-Protocol Communication: Supports both Modbus RTU and Modbus TCP protocols, which can communicate with on-site equipment through RS485, or perform remote monitoring and management through Ethernet.
- Easy Expansion: Through the built-in Ethernet interface, it can be easily connected to the SCADA system to realize remote monitoring and data collection.
- Industrial-Grade Reliability: Passed CE certification and complies with strict industrial electrical safety and electromagnetic compatibility standards.
______________________________________________________________________________________________________________
4. Structure and Composition
- CPU Core Module: Responsible for logical processing and calculation.
- I/O Interface Module: Provides 16-point digital input/output (DI/DO) interfaces.
- Communication Module: Integrates RS485 serial port and Ethernet interface.
- Power Module: Built-in DC24V power supply with stable power supply.
______________________________________________________________________________________________________________
5. Application Fields
- Mechanical Manufacturing: Such as machine tool control, packaging machinery, assembly line control.
- Building Automation: Such as HVAC (Heating, Ventilation and Air Conditioning), lighting control, access control systems.
- Process Control: Such as small process control systems for water treatment, waste gas treatment, etc.
- Transportation Facilities: Such as subway signal control, traffic light control systems.
______________________________________________________________________________________________________________
6. Installation and Maintenance
Installation
Adopt DIN rail installation or wall-mounted installation, and fix it on the industrial panel with special fixing screws. During installation, ensure that there is sufficient heat dissipation space around and avoid moisture intrusion.
Maintenance
During maintenance, it is recommended to cut off the DC24V power supply. Regularly check the wiring of the I/O interface and whether the terminals are loose, and ensure that the communication lines (RS485/Ethernet) are firmly connected to avoid system shutdown caused by communication failures.
————————————————————————————————-
