Schneider Sxwaspxxx10001
1. Overview
Schneider Sxwaspxxx10001 is a SmartX Controller (Automation Server) launched by Schneider Electric, mainly used in building automation and industrial control systems. It is compatible with the SpaceLogic platform and supports the LonWorks communication protocol, making it suitable for building distributed control networks.
This product is usually used in Building Management Systems (BMS) to coordinate the communication traffic between upper-level management systems (such as SCADA) and underlying equipment.
______________________________________________________________________________________________________________
2. Parameters & Technical Specifications
|
Parameter Category
|
Specific Indicators
|
Remarks
|
|---|---|---|
|
Network Interface
|
2 RS-485 ports
|
For LonWorks or Modbus communication
|
|
2 10/100Mbps Ethernet ports
|
Supports IP network connection
|
|
|
Compatibility
|
LonWorks bus technology
|
Compatible with LonMark standard
|
|
SpaceLogic system
|
Suitable for SpaceLogic platform
|
|
|
Certification & Compliance
|
Complies with RoHS / REACH standards
|
Environmental protection and safety specifications
|
|
Supports Zigbee wireless network
|
Supported by module expansion
|
|
|
Other Features
|
Supports BACnet/SC (Secure Connection)
|
Compatible with BACnet secure communication
|
|
Open Building Protocol support
|
Equipped with flexible system integration capabilities
|
______________________________________________________________________________________________________________
3. Product Features
- Hierarchical Communication Management: Effectively coordinates the communication traffic between upper-level (such as SCADA) and lower-level (such as field equipment) systems, optimizing network load.
- Powerful Protocol Support: Built-in LonWorks support, and compatible with Zigbee wireless network through expansion modules, with high compatibility.
- Security: Supports BACnet/SC (Secure Connection) nodes or routers, providing strong authentication and permission management functions.
- Eco-friendly Design: Complies with RoHS/REACH environmental standards and adheres to the concept of sustainable design.
______________________________________________________________________________________________________________
4. Structure & Composition
|
Components
|
Function Description
|
|---|---|
|
AS-P Module
|
Core processing unit, responsible for command execution and system logic processing
|
|
LonWorks Interface
|
Responsible for communication with LonWorks bus equipment, supporting RS-485
|
|
Ethernet Interface
|
Provides IP-based network communication capabilities
|
|
Power Module
|
Provides stable power supply support for the controller
|
|
Optional Communication Module
|
Such as Zigbee module, used to expand wireless communication capabilities
|
______________________________________________________________________________________________________________
5. Application Fields
- Building Automation (BMS): Used to monitor and control systems such as Heating, Ventilation and Air Conditioning (HVAC), lighting, and power monitoring.
- Industrial Automation: Acts as a distributed control node in production lines to manage field equipment.
- Energy Management: Used for power distribution management, energy consumption monitoring and optimization.
- Data Center Management: Monitors computer room environment, energy usage and equipment status.
______________________________________________________________________________________________________________
6. Installation & Maintenance Recommendations
|
Maintenance Stage
|
Key Recommendations
|
|---|---|
|
Installation
|
1. Confirm that the power supply voltage and grounding meet the requirements.2. Correctly connect the RS-485 bus according to the LonWorks network topology.3. Use Cat5e or higher specification network cables to connect the Ethernet port.
|
|
Configuration
|
Use SpaceLogic-related tools for parameter configuration, such as device address and communication rate.
|
|
Daily Maintenance
|
Regularly check the contact status of communication interfaces (such as RS-485 interfaces) to ensure no corrosion.Monitor system logs and handle abnormal alarms in a timely manner.
|
|
Firmware Upgrade
|
If you need to upgrade functions or fix vulnerabilities, it is recommended to perform it during non-production hours and ensure that the current configuration is backed up.
|
————————————————————————————————-
