1. Product Overview

2. Key Specifications

• Structure Type: Available in enclosed or open-frame configurations, tailored to specific application environments and corresponding IP rating protection requirements.
• Protection Rating: IP65/IP67 (note that protection ratings may vary slightly depending on specific model variants).
• Power Range: Designed for small to medium power outputs, perfectly suited for precision control applications.
• Speed & Torque: Features high rotational speed capability and moderate torque output, enabling high-speed positioning and exceptional dynamic response performance.

_______________________________________________________________________________________________________

3. Product Features

• High-Precision Control: Boasts micron-level position adjustment accuracy, with rapid acceleration and deceleration performance to minimize operation time and significantly boost overall production efficiency.
• Stable Operation & Low Noise: Delivers outstanding operational stability, ultra-low noise output, and reduced energy consumption, ensuring uninterrupted, stable performance of connected equipment during long-term operation.
• High Reliability: Equipped with a high insulation grade and superior protection rating, the motor withstands harsh industrial conditions, offering an extended service life and reduced maintenance frequency.

_______________________________________________________________________________________________________

4. Structure & Components

• Permanent Magnet Synchronous Motor (PMSM): The core driving component responsible for stable and efficient power output.
• High-Precision Encoder: Provides real-time feedback on shaft position and rotational speed, guaranteeing consistent and accurate motion control.
• Heat Dissipation System: Supports air cooling or water cooling options, meeting heat dissipation demands during high-power continuous operation.
• Mechanical Connection Parts: Equipped with keyway connections to ensure tight, reliable linkage between the motor and mechanical loads for efficient power transmission.

_______________________________________________________________________________________________________

5. Application Fields

• Automated Mechanical Equipment: Widely applied in CNC machine tools, automatic packaging lines, injection molding machines, and other precision automation equipment.
• Robotics Technology: Used as a drive component for robot joints, enabling precise, flexible motion control for industrial robots and collaborative robots.
• Electromechanical Equipment: Serves as a critical power component in industrial production lines and a full range of general electromechanical equipment.

_______________________________________________________________________________________________________

6. Installation & Maintenance

Installation

Maintenance

• Regular Inspections: Conduct routine checks on motor operating temperature, lubrication status, and bearing wear to detect potential faults in advance.
• Protection Checks: Verify the integrity of the protective housing (IP65/IP67 rated) to prevent dust, moisture, and other contaminants from entering the motor interior.
• Electrical Inspections: Inspect cable connections for tightness to avoid loosening caused by equipment vibration, ensuring stable electrical transmission.
