Schneider LXM62DD27D2100
1. Overview
The LXM62DD27D2100 is a dual-axis drive in the Lexium 62 series from Schneider Electric, with a rated current of 27 A, usually sold as an accessory package (including accessories). This product is mainly used in the field of industrial automation, providing efficient and reliable drive solutions, suitable for multi-axis machine tools, robots, palletizers and other equipment that require high-precision motion control.
__________________________________________________________________________________________________________
2. Specifications
|
Parameter
|
Specification
|
Description
|
|---|---|---|
|
Model
|
LXM62DD27D2100
|
Lexium 62 Dual-Axis Drive
|
|
Rated Current
|
27 A
|
Suitable for medium and large servo motors
|
|
Power Range
|
50W – 4.5kW
|
Covers a wide range of application needs
|
|
Control Method
|
Canopen + PTI
|
Supports two main communication protocols
|
|
Feedback
|
20-bit Single-turn Encoder
|
Provides high-resolution position signals
|
|
Speed Response
|
3 KHz
|
Fast speed response frequency
|
|
Safety
|
Built-in STO Terminal
|
Emergency stop function complying with safety standards
|
|
Built-in Features
|
Built-in Common DC Bus
|
Saves external component space
|
|
Dimensions
|
3.6L x 4.1W x 6.1H (mm)
|
Compact design
|
__________________________________________________________________________________________________________
3. Product Features
- Compact and Efficient: Compared with traditional drives, the volume is reduced by about 10%, saving installation space.
- High-Speed Response: With a speed response frequency of 3KHz, it is suitable for fast motion control scenarios.
- High Precision: Equipped with a 20-bit single-turn encoder to ensure high-precision motion positioning.
- Energy-Saving Design: Built-in common DC bus reduces system power consumption.
- Safe and Reliable: Built-in STO (Safe Torque Off) terminal meets industrial safety standards.
__________________________________________________________________________________________________________
4. Structure and Composition
The LXM62DD27D2100 is usually sold as an accessory package (including accessories), and its main components include:
- Main Drive Unit: The core motor control module.
- Power Module: Provides the current and power required for driving.
- Input/Output Terminals: Used to connect external devices such as sensors and emergency stop switches.
- Cooling System: Heat sink or fan to ensure stable operation of the drive under high load.
- Communication Interface: Communication ports supporting CANopen and PTI protocols.
__________________________________________________________________________________________________________
5. Application Fields
This drive is widely used in various industrial automation scenarios:
- Multi-axis Machine Tools: Such as machining centers, lathes, etc.
- Robots: Industrial robot joint drive.
- Conveyors and Palletizers: Used in material handling systems.
- Packaging Equipment: Motion control of high-speed packaging lines.
- Assembly Lines: Such as precise positioning control of fixtures.
__________________________________________________________________________________________________________
6. Installation and Maintenance
Installation Steps
- Power Connection: Ensure the power phase sequence is correct and connect the input terminals of the power module.
- Signal Wiring: Connect the motor phase wires, encoder signal wires, emergency stop switch (STO), etc.
- Communication Wiring: Connect the corresponding communication port according to the selected protocol (CANopen/PTI).
- Parameter Setting: Set parameters through Schneider’s configuration software (such as Lexium Config).
Maintenance Recommendations
- Regular Inspection: Check if the wiring terminals are loose, especially the power module and communication port.
- Clean the Heat Sink: Ensure the surface of the heat sink is free of dust to prevent overheating.
- Firmware Update: Regularly check the latest firmware version on Schneider’s official website to obtain the latest functions and security patches.
————————————————————————————————-
