Schneider HMIGTO6310
1. Overview
The HMIGTO6310 is a high-performance industrial-grade touch screen featuring a 12.1-inch color TFT display panel with SVGA resolution. It integrates powerful data processing capabilities and multiple communication interfaces, enabling stable operation in harsh industrial environments. With its rugged design and reliable performance, it is widely used in various industrial automation scenarios.
______________________________________________________________________________________________________________
2. Specifications
|
Specification Category
|
Detailed Value
|
|---|---|
|
Display Specifications
|
12.1-inch color TFT, Resolution 800×600 (SVGA)
|
|
Memory Capacity
|
96 MB Flash, expandable up to 4 GB
|
|
Operating Temperature
|
-10℃ to 60℃
|
|
Power Requirement
|
24 VDC, 0.71 A
|
|
Dimensions
|
Approx. W 315 mm x H 241 mm x D 56 mm (Approx. 12.4 x 9.5 x 2.2 inches)
|
|
Panel Cutout Dimensions
|
W 301.5 mm x H 227.5 mm
|
|
Weight
|
≤ 2.5 kg
|
|
Protection Level
|
IP65f (NEMA #250 TYPE 4X/13)
|
|
Communication Interfaces
|
Ethernet, RS232/RS485, USB
|
|
Storage Expansion
|
Supports microSD card
|
|
Software Platform
|
EcoStruxure Operator Terminal Expert (Vijeo Designer)
|
______________________________________________________________________________________________________________
3. Key Features
- Industrial-grade Durability: Complies with IP65 protection level, dust-proof and water-proof, suitable for harsh environments such as factory workshops.
- Large-capacity Storage: 96 MB Flash + 4 GB expandable memory, capable of storing a large amount of historical data and programs.
- High-resolution Display: 800×600 SVGA resolution, clear images, suitable for displaying complex curves and charts.
- Multi-language Support: Built-in multi-language interface, suitable for international projects.
- Rich Communication Capabilities: Built-in Ethernet, RS232/RS485 and USB interfaces, supporting multiple protocols.
- Environmentally Friendly: Complies with RoHS Directive and REACH Regulation.
_____________________________________________________________________________________________________________
4. Structure and Components
- Display Unit: 12.1-inch TFT color display screen.
- Control Unit: Internally integrated processor and memory chip.
- Communication Interface Board: Includes Ethernet, RS232/RS485, USB interfaces.
- Power Module: Integrated 24V DC power adapter.
- Mounting Frame: Mounting bracket conforming to GTO series standards.
______________________________________________________________________________________________________________
5. Application Areas
- Process Automation: Chemical, pharmaceutical, food and beverage industries.
- Industrial Manufacturing: Injection molding machines, packaging machines, CNC machine tools.
- Energy Management: Power stations, power distribution monitoring.
- Water Treatment: Water supply and drainage system control.
______________________________________________________________________________________________________________
6. Installation and Maintenance
Installation
- Panel Cutout: A cutout (approx. 301.5 x 227.5 mm) is required on the panel, with a thickness range of 1.6mm to 5mm.
- Grounding: Functional grounding must be performed, the grounding resistance should be less than 100Ω, and wires of at least 2mm² should be used.
- Protection: If a protection level higher than IP65 is required, a closed chassis or other protective measures should be adopted.
Maintenance
- Regular Inspection: Check the grounding resistance, communication interface connection status and display screen status.
- Cleaning and Maintenance: Clean the screen with a dry soft cloth, avoid using strong acid or alkali cleaners.
- Software Upgrade: It is recommended to regularly update the Vijeo Designer software and device firmware to obtain new functions and security patches.
————————————————————————————————-
