1. Overview

2. Core Specifications

• Screen Size: 10.4-inch TFT Color LCD
• Resolution: 640 x 480 VGA
• Memory: 96 MB On-board Memory
• Power Requirement: 24 V DC (some models support external power supply)
• Operating Temperature: 0°C – 55°C
• Protection Level: IP20 (Rear) / IP65 (Front Panel)

______________________________________________________________________________________________________________

3. Product Features

• High-Resolution Display: 640 x 480 VGA resolution, presenting delicate and clear images with support for 65,536 colors.
• Multi-Color Status Indicators: Equipped with multi-color LED indicators, which can be used to display device operation modes or statuses.
• Rich Communication Interfaces: Built-in 7 ports, supporting serial communication (RS232, RS485), Ethernet (TCP/IP), USB interface, and Web server function.
• Energy-Saving Design: Equipped with LED backlight, low power consumption (max. approx. 17W), and some models support lithium battery backup.
• Industrial-Grade Reliability: Complies with certifications such as CULus, CE, KCC, with shock resistance and vibration resistance, suitable for harsh industrial environments.

______________________________________________________________________________________________________________

4. Structure and Composition

• Display Module: 10.4-inch TFT Color LCD.
• Touch Screen: Resistive or capacitive multi-touch screen (depending on the model).
• Controller: Integrated processor (CPU) responsible for executing logic and communication tasks.
• Communication Module: Integrated with RS232/RS485/Ethernet ports.
• Power Module: Supports 24V DC power supply, and some models support external power input.
• Status Indicators: Multi-color LED status indicators are installed on the top or side of the panel.

______________________________________________________________________________________________________________

5. Application Areas

• Automated Equipment Control: Production lines, packaging machines, material handling equipment.
• Monitoring Systems: Real-time data monitoring, trend analysis, alarm display.
• Machine Interface: Graphical interface for machine operators.
• Environmental Monitoring: Displaying sensor data such as temperature, pressure, and flow rate.

______________________________________________________________________________________________________________

6. Installation and Maintenance

Installation Method

Maintenance Recommendations

• Regularly check whether the protective net is blocked by dust to maintain smooth heat dissipation.
• Check the firmness of the connecting cables to prevent loosening due to vibration.
• Use a soft dry cloth when cleaning the screen; avoid using alcohol or corrosive cleaning agents.
• Follow the electrical wiring specifications in the product manual to ensure stable power supply voltage and avoid equipment damage caused by overvoltage or undervoltage.
