Power Consumption:≤ 2W

Input Type:Discrete

Input Voltage Range:DC 24V

Response Time:≤ 1ms

Operating Temperature:-20°C to +70°C

Communication Interface:RS-485 Modbus RTU

Number of Inputs:16

Connection Type:M23 Connection

Reliability Rating:MTBF > 50,000 hours

Compliance Standards:CE, UL, CSA, EN 50178

    The Schneider Electric TM2AMO1HT M238 Discrete Input Module is designed to meet the stringent demands of modern industrial automation environments. Its compact size and robust design ensure reliable operation under a wide range of environmental conditions.

    Featuring 16 discrete input channels, this module provides efficient signal processing, making it suitable for applications requiring precise control over machinery and processes. Each channel is capable of handling up to 20mA current, ensuring compatibility with various sensors and actuators.

    Equipped with SPST relay contacts, the module ensures safe and reliable switching operations, crucial for safeguarding connected devices against potential damage. The use of a M23 connector facilitates easy installation and maintenance, reducing downtime and enhancing operational efficiency.

    With its broad temperature range of -25°C to +70°C for operation and -40°C to +85°C for storage, the TM2AMO1HT M238 is designed for long-term reliability in diverse industrial settings. This makes it an ideal choice for applications in harsh environments.

    Compliance with Modbus TCP/IP protocol enables seamless integration with other Schneider Electric products and third-party systems, enhancing system interoperability and data exchange capabilities. The modular design allows for scalability and flexibility, catering to evolving automation needs without the need for extensive system redesign.
