1. Overview

2. Core Parameters

3. Product Features

• Multi-Functional Output: The module supports both DC and AC relay outputs, expanding its application scope to adapt to diverse industrial power supply environments and load requirements, with strong compatibility for different working conditions.
• High Current Carrying Capacity: Each output point can bear a maximum current of 3A, enabling it to drive high-power loads stably. It eliminates the need for additional intermediate relays in most scenarios, simplifying the control circuit and reducing equipment costs.
• Excellent Durability: Adopting industrial-grade design and manufacturing standards, the BMXDRA1605 features outstanding anti-interference performance and operational stability. It can operate reliably in harsh industrial environments with dust, vibration and electromagnetic interference, ensuring long-term stable operation of the control system.
• Flexible Terminal Design: Equipped with a 20-point removable terminal block, it supports multiple wiring methods including cage clamp, screw type and spring type. This flexible design facilitates quick wiring, installation and later maintenance, greatly improving on-site construction and debugging efficiency.
• Eco-Friendly Design: The product complies with green industrial manufacturing standards, with a total lifecycle carbon footprint of 146 gCO₂e per unit. Additionally, its packaging uses at least 70% recycled cardboard, reducing environmental impact and meeting low-carbon and sustainable production requirements.

_______________________________________________________________________________________________________

4. Structure and Composition

• Module Body: The core component of the product, integrating 16-channel relay drive circuits, which realizes the conversion and output of control signals, and carries the core functional modules of the whole product.
• Terminal Block: A 20-point detachable terminal block, which is used for external wiring connection of load and power supply. The detachable design makes it convenient for replacement, maintenance and on-site wiring adjustment, reducing the difficulty of later maintenance.
• Connector: FCN connector, a dedicated interface for connecting with the PLC main unit or backplane, ensuring stable signal transmission between the module and the PLC control system, with good anti-loosening and anti-interference performance.
• Rail Buckle: Specially designed buckle structure for quick installation on the AM1 FD rail, realizing firm fixation of the module, convenient for standardized installation in the control cabinet and saving installation space.
