Schneider ATV930D45N4Z
1. Overview
The ATV930D45N4Z is a cabinet-mounted frequency inverter launched by Schneider Electric, with a power of 45kW, suitable for industrial power environments ranging from 380V to 480V. This product complies with RoHS and REACH regulations, featuring environmental protection performance, and has obtained the Green Premium™ certification, emphasizing its sustainable development capability throughout the entire life cycle.
_______________________________________________________________________________________________________
2. Core Specifications
|
Parameters
|
Specifications
|
|---|---|
|
Rated Power
|
45 kW
|
|
Rated Voltage
|
380V – 480V
|
|
Protection Level
|
IP20 (Cabinet-mounted Type)
|
|
Packaging
|
Cardboard Packaging (containing at least 70% recycled cardboard)
|
|
Environmental Protection
|
Passed RoHS and REACH tests, with Green Premium™ certification
|
_______________________________________________________________________________________________________
3. Product Features
- Cabinet-mounted Design: Specifically designed for installation in distribution cabinets, with a compact size that facilitates integration with other electrical components.
- Green and Environmental Protection: Adopts a mercury-free design, uses a large amount of recycled cardboard for packaging materials, the entire product life cycle complies with green procurement principles, and provides environmental performance labels and data.
- Intelligent Interface: Supports Ethernet SFTP interface, facilitating digital communication with PLC or SCADA systems.
_______________________________________________________________________________________________________
4. Structure and Composition
The structural design of this frequency inverter complies with industrial safety standards (EN 954-1 Category 1, IEC/EN 61508 SIL1), is equipped with a braking device (selected according to specific models), and provides three installation methods: independent installation (IP21), side-by-side installation (IP20) and separate installation (IP20).
_______________________________________________________________________________________________________
5. Application Fields
- Mechanical Transmission: Large motor drive systems.
- Ventilation and Pump Industry: Variable speed control of fans, water pumps and other fluid machinery.
- Manufacturing Automation: Production line equipment that requires reliable frequency conversion control.
_______________________________________________________________________________________________________
6. Installation and Maintenance
- Installation: It is recommended to install in a well-ventilated distribution cabinet and wire in accordance with IEC/EN 60204-1 standard.
- Wiring: Supports three-phase power wiring and provides various grounding and current protection options.
- Maintenance: Regularly check the braking device (if any) and cooling system to ensure a dust-free and corrosion-free environment, so as to maintain the performance of its IP20 protection level.
————————————————————————————————-
