Schneider ATV630C16N4
Product Overview
The ATV630C16N4 is a high-power frequency inverter under the Altivar Process series of Schneider Electric, with a power of 160kW (250HP) and a voltage range of 380-480V. Belonging to the ATV630 series, this model is mainly used to drive heavy-duty motors, featuring high-performance process control and energy-saving functions.
______________________________________________________________________________________________________________
Core Parameters & Technical Specifications
|
Parameter
|
Specification
|
|---|---|
|
Power
|
160kW (250HP)
|
|
Rated Voltage
|
380-480V
|
|
Protection Level
|
IP00 (No Protection)
|
|
Mounting Type
|
Type B (Side-by-Side Mounting, IP20); Type C (Separate Mounting, IP20)
|
|
Dimensions
|
320mm (W) x 852mm (H) x 390mm (D)
|
|
Weight
|
Approx. 82kg
|
|
Input/Output
|
3 Analog Inputs (Voltage/Current), 8 Discrete Inputs, 2 Analog Outputs, 3 Relay Outputs
|
|
Communication Interface
|
RJ45 Ethernet/Modbus TCP, Modbus Serial (4.8-38.4 kbps)
|
|
Power Supply
|
Single-phase or Three-phase Power Supply, Supporting Line Contactor Upstream Interruption
|
|
Additional Functions
|
Embedded Power Measurement and Energy Consumption Dashboard, Process Monitoring, Drift Monitoring, Green Premium™ Certification
|
______________________________________________________________________________________________________________
Product Features
- High Power Density & Process Control: Designed specifically for the process industry, it supports precise control of Asynchronous and Synchronous motors, suitable for heavy-duty equipment such as fans, pumps, and compressors.
- Energy Efficiency & Savings: Compliant with Green Premium™ environmental standards, it has energy-saving start/stop functions and drift monitoring to help reduce energy consumption and monitor carbon footprint.
- Powerful Diagnostic Functions: Equipped with 3 LED local diagnostic lights and 3 LED dual-color communication status lights, facilitating quick troubleshooting and status monitoring.
- Environmental Compliance: The product complies with RoHS Exemption, REACH Regulation, EU RoHS Directive, and China RoHS Management Measures, contains no mercury, and supports waste recycling.
______________________________________________________________________________________________________________
Structure & Composition
- Power Module: Receives and converts input power, providing low-voltage DC power required for internal electronic components.
- Drive Module: The core power conversion unit, responsible for outputting variable frequency and voltage to control the motor.
- Control Module: Embedded processor (CPU) that executes control algorithms, processes input signals, and sends control instructions to the drive module.
- Communication Module: Supports Ethernet and Modbus communication, facilitating integration with upper computers or PLCs.
- Display & Operation Panel: Provides local control and status display (usually an LCD screen and function keys).
______________________________________________________________________________________________________________
Typical Application Fields
- Pumps & Compressors: Occasions requiring constant flow control.
- Fan Systems: Such as high-power fans in HVAC (Heating, Ventilation, and Air Conditioning) systems.
- Mining & Metallurgy: Heavy-duty drive equipment, such as vertical filter presses.
- Energy & Chemical Industry: Occasions requiring high-precision process control.
______________________________________________________________________________________________________________
Installation & Maintenance Guidelines
Installation Notes
- Installation Spacing: It is recommended to reserve at least 110mm of space around the equipment to ensure heat dissipation and maintenance access.
- Mounting Type: Type B models are mounted side-by-side, and Type C models are mounted separately; the selection should be based on the on-site environment.
- Power Wiring: Upstream interruption can be achieved through a line contactor; it is recommended to use junction boxes complying with IEC/EN standards.
Maintenance Points
- Regular Cleaning: Keep the heat dissipation vents ventilated to prevent dust blockage from affecting heat dissipation performance.
- Firmware Update: It is recommended to regularly check the firmware version released by Schneider official to obtain the latest function optimizations and security patches.
- Environmental Monitoring: Pay attention to the temperature, humidity, and electromagnetic interference level of the operating environment to ensure working within the rated parameters.
————————————————————————————————-
