1. Product Overview
The AP8653 is a 2G series rack-mounted PDU launched by Schneider Electric, featuring a ZeroU design that fits directly into the 1U rails on both sides of the rack without occupying additional vertical space. It not only provides a rich socket configuration (21 C13 + 3 C19) but also enables independent metering and switch control for each socket.
_______________________________________________________________________________________________________
2. Key Specifications
|
Parameter
|
Specification
|
|---|---|
|
Rated Current
|
32A
|
|
Rated Power
|
7.4 kW
|
|
Power Supply Voltage
|
230V (IEC309)
|
|
Socket Configuration
|
21 C13 + 3 C19
|
|
Metering Method
|
Metered by Outlet
|
|
Dimension
|
1U Height (ZeroU Design)
|
|
Power Factor
|
High Power Factor, Equipped with Power Factor Correction Capacitor
|
|
Communication Interface (If Any)
|
Network/Serial Port for Remote Monitoring (Refer to Specific Model Manual)
|
_______________________________________________________________________________________________________
3. Product Features
- ZeroU Design: No need to occupy vertical rack space, maximizing the use of rack height.
- Metered by Outlet: Each C13/C19 socket is equipped with independent power metering function, supporting refined energy management.
- Independent Switch: Each socket can be switched on and off individually, facilitating remote control of equipment power supply.
- High Power Factor Correction: Built-in Power Factor Correction (PFC) capacitor to improve power utilization efficiency.
- Durable and Reliable: Adopts high-quality industrial-grade components, suitable for high-density computer room environments.
_______________________________________________________________________________________________________
4. Structure and Composition
- Main Unit: Includes internal circuit board, power factor correction capacitor and power input part.
- Outlet Panel: Provides 21 C13 and 3 C19 sockets.
- Metering/Switching Module: Independent metering and switching hardware equipped for each socket.
- Enclosure: Made of metal material, providing structural support and electromagnetic shielding.
_______________________________________________________________________________________________________
5. Application Areas
- Data Centers: Power management for servers and storage devices.
- Communication Rooms: Power distribution for network equipment, routers and switches.
- High-Density IT Rooms: Scenarios requiring refined power consumption management.
- Edge Computing Nodes: Environments with limited space and efficient power management needs.
_______________________________________________________________________________________________________
6. Installation and Maintenance
Installation
- Fit directly into the 1U rails on both sides of the rack (ZeroU design) without occupying additional space.
- Ensure that the rack power load does not exceed the rated power of the PDU.
- Connect the power cord to the power socket at the back of the rack as needed.
Maintenance
- The product adopts a closed design, no frequent maintenance is required. It is recommended to regularly check the heat dissipation in the rack.
- If the remote monitoring function is enabled, it is recommended to regularly check the software status.
————————————————————————————————-
