Schneider AEG PC-0984-485
1. Overview
PC-0984-485 is a compact, modular programmable logic controller (PLC) designed for process control and automation systems in industrial field applications. Adopting a modular architecture, it can be freely combined with the same series of I/O, communication and function expansion modules to realize flexible system configuration. Classified under the “PC-0984” product series in Schneider’s part number system, this model is ideal for industrial environments requiring high reliability and easy maintenance.
2. Key Technical Specifications
Rated Power Supply: 24 V DC (230 V AC optional)Operating Temperature Range: -20 °C to +55 °C (Industrial Grade)Storage Capacity: 256 KB program memory, 64 KB data memory (subject to optional CPU module)CPU Speed: Up to 100 MHz (based on the latest ARM Cortex-A series)Communication Interfaces: Ethernet (TCP/IP), PROFINET, Modbus TCP/RTU, CANopen (via optional communication modules)I/O Expansion: Supports digital, analog, counter and pulse I/O modules; up to 64 I/O expansion slots for single unitSafety Functions: Safety I/O and safety instruction set compliant with IEC 61508 SIL 2/3 safety standardsCertifications: CE, UL, CSA, EN 60947-1, EN 61800-5-1 and other international certifications
3. Product Features
- Modular Design: Hot-swappable CPU, I/O, communication and function modules enable quick on-site replacement and upgrade.
- High Reliability: Industrial-grade components deliver anti-interference, anti-vibration and shock resistance, suitable for harsh working conditions.
- Flexible Communication Capability: Multi-protocol interconnection via optional communication modules meets hybrid network requirements of fieldbus and industrial Ethernet.
- Safety Control: Built-in safety instructions and safety I/O support functional safety applications, complying with SIL 2/3 requirements.
- Easy Maintenance: Modular structure facilitates fast fault location, supporting online diagnosis and remote monitoring.
- Strong Compatibility: Compatible with Schneider’s legacy Modicon series software and programming environments (Unity Pro / EcoStruxure Control Expert), reducing migration costs.
4. Structure & Components
- CPU Module: Core processing unit providing computing, storage and basic communication functions
- Power Supply Module: Supplies 24 V DC (or 230 V AC) with overvoltage and overcurrent protection
- I/O Expansion Modules: Including digital input/output, analog input/output, counter/pulse modules, etc.
- Communication Modules: Optional Ethernet, PROFINET, Modbus and CANopen modules
- Optional Safety Modules: Safety I/O, safety relays and emergency stop circuits
- Chassis/Rail: Modular chassis compliant with IEC 60204-1, directly mountable on rails or in electrical cabinets
5. Typical Application Fields
- Industrial Automation: Production line control, assembly robots, CNC machine tools
- Process Control: Continuous or batch production processes in chemical, petroleum, metallurgy, food and beverage industries
- Energy Management: Distribution automation, substation monitoring, renewable energy (solar PV, wind power) inverter control
- Building & Facility Management: Centralized control of HVAC, lighting and security systems in large buildings
- Transportation: Local control of rail transit, subway signaling and power supply systems
————————————————————————————————-
