Schneider AEG PC-0984-385 Power Distribution Module

PC-0984-385 is a standard distribution board of the "PC" series, mainly designed for power convergence and distribution. Compliant with IEC 61439 standard, it features excellent anti-interference performance and mechanical strength, enabling long-term stable operation under various environmental conditions

Schneider AEG PC-0984-385

Overview

PC-0984-385 is a standard distribution board of the “PC” series, mainly designed for power convergence and distribution. Compliant with IEC 61439 standard, it features excellent anti-interference performance and mechanical strength, enabling long-term stable operation under various environmental conditions.

Key Parameters

Rated Voltage: 400V AC (3-phase 4-wire)Rated Current: 63A (NEMA/IEC 63A)Rated Short-circuit Breaking Capacity (Icu): 6kA (higher grade optional)Installation Dimensions: 1000mm (W) × 2000mm (H) × 450mm (D) (standard depth)Enclosure Material: Cold-rolled steel with anti-corrosive coating (EN 10353)Protection Class: IP30 (IP42/44 optional)Operating Temperature Range: -25°C to +55°CEnvironmental Adaptability: UV-resistant, corrosion-resistant, impact-resistant

Product Features

Modular Design: The internal structure adopts a standard DIN rail system, facilitating quick installation of accessories such as circuit breakers, relays and terminal blocks.
High Reliability: The structure design complies with IEC 61439, providing excellent short-circuit withstand capacity and electromagnetic interference resistance.
Flexible Expansion: Reserved multiple combination spaces (e.g., 1M, 3M, 5M) for flexible configuration according to actual load requirements.
Ergonomics: Equipped with transparent observation window and misoperation-prevention door lock structure, convenient for on-site inspection and safe maintenance.
Environmental Protection & Energy Saving: Adopts low-noise circuit breakers and oil-free switch components, fully compliant with RoHS environmental standards.

Structure & Composition

Main Cabinet Body: Integral enclosure welded by cold-rolled steel plate, surface coated with anti-corrosive paint.
Back Panel: Steel or aluminum backboard providing mounting support and fixed wiring holes.
Wiring Holes: Multiple specifications of wiring holes (20mm, 25mm, 40mm) reserved on sides or back for easy cable entry and exit.
Baffle/Door: Lockable front door (transparent or opaque optional) with internal terminal block supports.
Rail System: Standard DIN rails (Top, Bottom, Middle) for installing modular components.
Grounding Bar: Equipped with grounding busbar or grounding bar to ensure reliable system grounding.
Accessories: Cable entry seals, gas discharge valves and insulation supports are provided as standard.

Typical Application Fields

Industrial Plants: Production line power distribution, machine tool power supply, power control centers.
Commercial Buildings: Main and distribution cabinets for office buildings and shopping malls.
Public Facilities: Power distribution systems for hospitals, schools and airports.
Energy Systems: Grid-connected/off-grid power distribution for photovoltaic inverters and energy storage systems.
Data Centers: Power distribution and protection matched with UPS and PDU.

Installation & Maintenance Key Points

Installation

Install in a well-ventilated and dry environment, and keep sufficient heat dissipation gap (usually 100mm) between the cabinet back and the wall. Strictly follow the wiring diagram for cable laying during installation to avoid excessively small cable bending radius.

Grounding

Ensure the grounding busbar is reliably connected to the building grounding system, and the grounding resistance meets local specification requirements.

Commissioning

Conduct insulation resistance test, grounding continuity test and switch function test before power-on.

Daily Inspection

Regularly check the tightness of terminal blocks, insulation status and integrity of door locks. Perform functional calibration on thermal components (e.g., thermal relays).

Cleaning & Maintenance

Keep the cabinet interior dry and free from dust accumulation. Use compressed air or soft brush for dust cleaning when necessary.

Replacement & Upgrade

Cut off the main power supply and use insulated tools when replacing circuit breakers or adding modules, strictly following the principle of “disconnect first, connect later”.

————————————————————————————————-
