Schneider AEG MM-PM10-200

The MM-PM10-200 is a PanelMate Plus series HMI (Human-Machine Interface) launched by Schneider Electric (formerly AEG). As a 10-inch (approx. 254 mm) touch screen operation panel, it is specially designed for on-site monitoring and operation of Modicon PLC systems. Adopting a modular design, this panel can be used with Schneider’s Power-Module, IO-Module and other accessories to achieve compact and reliable on-site control.

Key Technical Specifications

• Display Size: 10-inch (254 mm) TFT color touch screen
• Resolution: 800 × 480 pixels (WVGA)
• Supply Voltage: 18 – 30 V DC, Power Consumption: approx. 11 W
• Operating Temperature: -20 °C – +60 °C, Optional Protection Class: IP20 / IP54
• Communication Interfaces: Multiple fieldbuses including Modbus RTU, Profibus-DP, Ethernet/IP and CANopen
• Optional Function Modules: Alarm light, keyboard, extended I/O, wireless module, etc.
• Certifications: CE, UL, CSA and other international safety certifications

Product Features

1. Modular Structure: The panel body, backplane and base are fixed by bolts or welding, enabling quick on-site assembly and maintenance.
2. High Reliability: Equipped with industrial-grade components, it supports redundant power supply and hot standby, ideal for critical process procedures.
3. Multi-protocol Compatibility: Built-in multiple fieldbus protocols, realizing seamless connection with Modicon PLC, Power-Module and IO-Module directly.
4. User-friendly Interface: Supports graphical editing, script programming, alarm history recording and other functions for intuitive operation.
5. Environmental Adaptability: Dustproof and waterproof design (IP54) with wide operating temperature range, suitable for workshops, on-site sites, outdoor and other environments.

Structure & Components

• Display Unit: 10-inch TFT touch screen with built-in backlight
• Control Mainboard: Integrated with CPU, storage and communication chips, responsible for screen rendering and protocol processing
• Power Module: Accepts 18-30 V DC input and provides internal voltage stabilization
• Cabinet & Base: Metal or high-strength plastic cabinet; the base can be fixed by bolts or welding for easy cabinet installation
• Optional Extension Modules: Alarm light, keyboard, wireless communication, additional I/O interfaces, etc.

Typical Application Fields

• Automated Production Lines: Monitor PLC status, set process parameters and display alarm information
• Process Control: On-site operation and data acquisition in chemical, food, pharmaceutical and other industries
• Energy & Power: Operation monitoring and remote diagnosis of distribution stations and substations
• Building Automation: Centralized management of air conditioning, lighting and security systems
• Transportation Facilities: Status display of public facilities such as subways, light rails and parking lots

Installation & Maintenance Notes

• Pre-installation Check: Confirm the supply voltage is within 18-30 V DC range, and check the grounding of the cabinet or on-site environment
• Fixing Method: The base can be fixed by 4×M16 bolts or welding; for cabinet multi-screen connection, use 8×M8 hexagon socket bolts for connection
• Wiring Standards: Comply with IEC 60204-1 electrical safety standards; separate signal wires from power wires to avoid interference
• Software Configuration: Use Schneider’s Vijeo Designer or EcoStruxure Operator Terminal software for screen design and parameter setting
• Regular Inspection: Check touch screen response, interface connection and power stabilization every 6 months; inspect the dustproof and waterproof sealing of IP54-rated cabinets
• Fault Diagnosis: The panel has a self-test function; when a fault occurs, locate the problem through built-in diagnostic logs or remote PLC alarm information
