Schneider AEG MM-08MP-001
1. Overview
MM‑08MP‑001 is one of the MM Series (Modular‑Mount) low-voltage distribution products launched by Schneider Electric after the acquisition of Germany’s AEG. Featuring modularization, stackability and flexible combination, this series is suitable for multiple scenarios including industrial power distribution, building equipment rooms, energy stations and rail transit. Adopting a Rear Busbar (MLS) structure, MM‑08MP‑001 is specially designed for 8 kA short-circuit current, delivering high reliability and compact layout.
2. Key Technical Parameters
| Parameter | Typical Value |
|---|---|
| Rated Voltage | 400 V / 690 V AC |
| Rated Current | 63 A (125 A, 250 A optional) |
| Rated Short-Circuit Current | 8 kA (10 kA, 15 kA, 25 kA optional) |
| Power Capacity | ≤ 45 kW (depending on module combination) |
| Operating Temperature Range | –25 °C - +55 °C |
| Protection Class | IP20 (Internal) / IP54 (Enclosure) |
| Mounting Method | Wall-mounted, frame-mounted or base-fixed (bolted or welded) |
| Module Dimensions | 300 mm (W) × 400 mm (D) × 200 mm‑800 mm (H), stackable |
| Wiring Method | Rear Busbar (MLS) or Top Busbar (MLS‑600) structure |
| Accessories | 4 × M16 side fixing bolts, 8 × M8 inter-cabinet connecting bolts |
| Certifications | IEC 61439, CE, RoHS, REACH, Green Premium™ (Environmental-friendly) |
| Warranty Period | 18 months |
3. Product Features
- Modular Design: With a unit width of 300mm, it supports horizontal or vertical stacking for quick on-site capacity expansion.
- Flexible Busbar Layout: Offers two structures (Rear Busbar MLS and Top Busbar MLS‑600) to meet diverse power distribution space requirements.
- High Short-Circuit Withstand Capacity: The maximum rated short-circuit current can reach 25 kA, ideal for high-impact industrial environments.
- Compact & Easy Maintenance: IP20 internal protection and IP54 enclosure protection, equipped with detachable side panels and quick-connect terminals for convenient maintenance.
- Environmental Compliance: Conforms to EU RoHS, REACH and Schneider Electric’s Green Premium™ environmental standards, realizing full-life-cycle recyclability.
- Versatile Mounting Options: Wall-mounted, frame-mounted or base-fixed installation adapts to equipment rooms, distribution cabinets, rail transit and other on-site scenarios.
4. Structure & Components
- Enclosure: Die-cast or stamped metal parts with IP54 protection, equipped with dustproof and waterproof seals.
- Busbar System: Copper or aluminum busbars with rear or top layout for easy electrical connection between modules.
- Terminal Block: Standard screw-type terminals supporting quick plug-in and pull-out.
- Fixings: 4 × M16 bolts (base fixing) or 8 × M8 bolts (inter-cabinet connection).
- Heat Sink: Built-in heat dissipation structure ensures stable operation in high-temperature environments.
- Distribution Unit: Optional functional modules such as circuit breakers, contactors and relays to meet different protection needs.
6. Installation & Maintenance Essentials
On-site Preparation
- Ensure the temperature of the installation location is within the range of –25 °C - +55 °C.
- Check the bearing capacity of walls or frames to meet the requirements of bolted or welded fixation.
Fixing Methods
- Wall-mounted: Fix the base to walls or brackets with 4 × M16 bolts.
- Frame-mounted: Directly weld or bolt to the distribution cabinet frame.
- Base-fixed: Reserve a gap of over 20 mm at the cabinet bottom for heat dissipation.
Electrical Connection
- Arrange busbars according to Rear Busbar or Top Busbar scheme to ensure alignment between busbar terminals and adjacent modules.
- Connect phase lines, neutral lines and protective grounding via standard screw terminals, with torque referring to IEC 61439 standard.
————————————————————————————————-
