Schneider AEG MA-P884-001 Power Module

MA-P884-001 is a power supply module under the Schneider AEG product line, specially designed for installation in remote I/O master-slave racks (H8XX-100/103/107, H8XX-209).

Schneider AEG MA-P884-001

Overview

MA-P884-001 is a power supply module under the Schneider AEG product line, specially designed for installation in remote I/O master-slave racks (H8XX-100/103/107, H8XX-209). It provides stable DC power supply for internal rack components including I/Os, CPUs and communication boards, serving as a critical power supply unit in low-voltage distribution systems.

Key Technical Specifications

Item	Specification
Model	MA-P884-001
Input Voltage	120V / 220V AC (Single-phase)
Compatible Racks	H8XX-100, H8XX-103, H8XX-107, H8XX-209
Slot Width	1.0 U (Single slot)
Output Voltage	+5.0V, +4.3V, -5.0V (Optional)
Output Current	+5.0V ≈ 5A, +4.3V ≈ 10.1A, -5.0V ≈ 0.5A
Power	≤ 45W (Depends on output combination)
Operating Temperature	-25°C – +55°C
Protection Grade	IP20 (Internal) / IP54 (Enclosure)
Mounting Method	Wall-mounted, frame-mounted or base-fixed (Bolted or welded)
Dimensions	Width 300mm, Depth 400mm, Height 200mm – 800mm (Stackable)

Product Features

Modular Design: Single-slot width enables flexible stacking and expansion inside the rack.
Multi-voltage Output: Delivers three DC voltages (+5V, +4.3V, -5V) to meet power supply requirements of different I/O cards.
High Reliability: Complies with international low-voltage distribution standards such as IEC 60364 and EN 50173, equipped with 10kA short-circuit protection and overload protection.
Wide Temperature Range: Operates stably from -25°C to +55°C, suitable for harsh industrial field environments.
Easy Maintenance: IP54-rated enclosure with quickly replaceable internal components to minimize downtime.

Structure & Components

Power Transformer: Converts AC input to required low-voltage DC.
Rectifier/Filter Circuit: Provides regulated DC output with low ripple.
Output Terminal Block: Corresponding to +5V, +4.3V and -5V respectively, equipped with screw-type terminals.
Protection Unit: Includes fuse, thermal relay and short-circuit detection circuit.
Mounting Bracket: Compatible with wall-mounted, frame-mounted and base-fixed installation methods.

Typical Application Fields

Industrial Automation: Power supply for remote I/Os in assembly lines, packaging machinery and CNC machine tools.
Process Control: Power supply for fieldbus (Modbus, Profibus) modules in chemical, petroleum and energy stations.
Building Distribution: Sub-distribution cabinets and floor control systems in large-scale buildings.
Transportation Facilities: Power supply for control cabinets in rail transit and airport ground equipment.

Installation & Maintenance Notes

Pre-installation Check: Confirm rack model and slot width match; verify input power phase and voltage.
Fixing Method: Adopt M16×4 bolts or welded base to ensure vibration resistance.
Wiring: Use terminals compliant with IEC 60204 standard for reliable contact and easy maintenance.
Heat Dissipation: Keep vents unobstructed; install heat sinks or fans if necessary.
Regular Inspection: Check output voltage, ripple and protection device functions every 12 months; replace the module promptly if abnormalities are found.

————————————————————————————————-
