Schneider AEG AS-B883-111
The AS‑B883‑111 is an analog input module belonging to the AEG (Modicon) product line under Schneider Electric, and it is part of the 800 Series I/O components. Engineered specifically for process signal acquisition in industrial field environments, this module converts multi-channel analog signals (voltage/current) into digital signals, enabling real-time monitoring and control by PLCs or controllers.
Key Specifications
| Parameter | Details |
|---|---|
| Model | AS‑B883‑111 |
| Type | Analog Input Module |
| Number of Channels | 8 analog input channels (each configurable independently) |
| Supported Signals | 0–10 V, 4–20 mA (standard signals for common industrial sensors) |
| Resolution | 12-bit (delivering digital output ranging from 0 to 4095) |
| Supply Voltage | 24 V DC (complying with the unified power supply standard of the 800 Series) |
| Operating Temperature Range | -20 °C to +60 °C (suitable for general industrial environments) |
| Protection Class | IP20 (for indoor installation only) |
Product Features
-
High ReliabilityAdopting a modular and plug-and-play design, the module allows for quick on-site replacement and maintenance, minimizing system downtime.
-
Strong CompatibilityIt is fully compliant with the communication protocols of Modicon 800 Series PLCs and can be directly integrated into the system bus without the need for additional adapters.
-
Multi-Signal CompatibilitySupporting both voltage and current analog signals, the module meets the connection requirements of various industrial sensors.
-
Digital PrecisionThe 12-bit resolution ensures high-fidelity acquisition of analog data, making it ideal for precision scenarios such as process control and industrial monitoring.
-
Easy ConfigurationChannel calibration, range setting, and other parameter configurations can be completed on a PC via Schneider’s EcoStruxure software.
Structure and Components
- Module Body: The metal enclosure houses 8-channel analog input circuits, with each channel equipped with signal conditioning, filtering, and A/D conversion units.
- Terminal Block: Each channel is configured with independent voltage/current input terminals, featuring clear markings to prevent incorrect wiring.
- Power Interface: 24 V DC power supply terminals that are compatible with the PLC main power supply.
- Indicator Lights: Status indicators display module power supply, fault, and communication status in real time.
Typical Application Fields
- Material Handling Systems: Collects signals from sensors for weight measurement, position detection, and pressure monitoring to enable automated control of material flow.
- Packaging Machinery: Monitors process parameters such as temperature, flow rate, and liquid level, ensuring consistent packaging quality.
- Process Automation: Applied in chemical, food, pharmaceutical, and other industries for real-time monitoring of process variables.
- Machine Vision Systems: Provides analog input for parameters like light source intensity and temperature, supporting auxiliary image processing.
Installation and Maintenance Guidelines
Installation
Install the module into the I/O tray or cabinet slot of the 800 Series with the power turned off, and ensure that the locking clips are securely fastened.
Wiring
Connect voltage or current signals according to the markings on the terminal block. Caution should be exercised to avoid signal line crossing or incorrect connections.
Configuration
Use EcoStruxure or the corresponding PLC programming software to calibrate channel ranges, then save the settings and download them to the controller.
Routine Inspection
Regularly check the tightness of terminal connections, the status of indicator lights, and whether there is dust or corrosion on the module surface.
Troubleshooting
In case of communication abnormalities or signal distortion, first check the power supply, wiring connections, and module indicator lights. If necessary, the system can be restored to normal operation simply by replacing the module.
————————————————————————————————-
