Schneider AEG AS-B872-100 I/O Module

Schneider AEG AS-B872-100

The AS-B872-100 is a Modicon 800 series I/O module launched by Schneider Electric (formerly AEG), specially designed for industrial automation systems to deliver reliable digital/analog signal acquisition and output functions. Operating at 24V DC, this module is suitable for harsh industrial environments, supports DIN rail mounting, and is compatible with the AS-i bus network.

Key Technical Specifications

Operating Voltage: 24V DCInput Type: Digital Input (8 channels)Output Type: Digital Output (8 channels) or Analog Output (4 channels, subject to specific models)Input Current: 5mA per channelOutput Current: 14mA per channelCommunication Interface: Modbus RTU (RS-485)Operating Temperature Range: -10°C to 60°CStorage Temperature Range: -40°C to 80°CProtection Class: IP20Dimensions: 115mm × 89mm × 63mm (H × W × D)Weight: Approximately 450g

Product Features

High Reliability: Adapted to harsh industrial environments with overvoltage, short-circuit and reverse polarity protection.
Versatile Communication: Supports industrial protocols like Modbus RTU for seamless integration with upper-level systems.
Flexible Networking: Works as an AS-i slave device, compatible with multiple modules including digital input, digital output, and analog input/output units.
Diagnostic Functions: Equipped with status indicators, fault detection and diagnostic information for convenient on-site maintenance.
Easy Configuration: Rapid parameter setting and network layout can be completed with Schneider’s dedicated AS-i configuration software.

Structure & Components

Module Body: Metal housing with built-in PCB and input/output terminal blocks.
Terminal Blocks: Screw-type wiring design supporting quick plug-and-play operation.
Indicators: Power, communication and fault status lights for quick on-site operation status judgment.
Connectors: Standard AS-i interfaces (e.g., AS-8535-000) for bus cascading.

Typical Application Fields

Signal acquisition and control of sensors/actuators in automated production lines
Discrete I/O requirements in process control systems (e.g., chemical, food & beverage industries)
Status monitoring of logistics and warehousing equipment
Switch control in energy management systems

Installation & Maintenance Guidelines

Installation Method

Fix via DIN rail, ensure horizontal installation of the module and correct connection with bus ports.

Wiring Notes

Input/output terminals adopt screw fixation; confirm voltage rating before wiring to avoid module damage caused by wrong connection.

————————————————————————————————-

Main brand

ABB Allen-Bradley Alstom Bently Emerson Foxboro

GE MOOG Schneider Woodward HIMA Honeywel Triconex & more

Contact our professional team today for customized solutions to meet your electrical component needs.

📧 x13806028623@gmail.com / johnedward.zch@gmail.com

📞 +86 18250705533（Whatsapp）丨Sales Manager : Jinny/John

———————————————————————-

For more ABB products, please click here
