Schneider AEG AS-9584-000
1. Overview
The AS‑9584‑000 is a three-phase asynchronous induction motor with IE2 efficiency class, featuring a cast iron housing and designed for continuous operation in temperatures ranging from -20 °C to +40 °C. Fully compliant with NEMA 145 and IEC 60335‑2‑30 standards, this motor boasts dust-proof, waterproof (IP55) and corrosion-resistant structural properties, making it ideal for harsh industrial working conditions.
2. Key Specifications
| Parameter | Value | Description |
|---|---|---|
| Rated Power | 7.5 kW (10 HP) | Common power rating for industrial applications |
| Rated Voltage | 380 V / 400 V / 415 V (3-Phase) | Compatible with mainstream power grids in Europe and Asia |
| Rated Frequency | 50 Hz / 60 Hz | Dual-frequency optional for global use |
| Rated Speed | 1450 r/min (50 Hz) / 1800 r/min (60 Hz) | Standard synchronous speed |
| Rated Current | 13.5 A (380 V) | Reference value under rated voltage |
| Power Factor | 0.85 (Full Load) | Meets IE2 efficiency grade requirements |
| Efficiency | 86 % (IE2) | Compliant with international energy efficiency directives |
| Insulation Class | Class F (155 °C) | Ensures long-term stable operation |
| Protection Class | IP55 | Dust and water protection |
| Mounting Method | Flange Mount (B3) / Threaded Mount (C1) | Customizable for on-site requirements |
| Weight | Approx. 55 kg | Weight of cast iron housing |
3. Structure & Components
- Stator: Laminated with high-permeability silicon steel sheets and equipped with three-phase copper windings to provide a stable magnetic field.
- Rotor: Squirrel-cage aluminum conductor (standard) or copper conductor (optional), with rotor core made of high-strength cast iron.
- Bearings: Double-row deep groove ball bearings with dust covers, supporting both axial and radial loads.
- End Covers: Cast iron end covers with built-in cooling fins to enhance heat dissipation efficiency.
- Terminal Box: Compliant with IEC 60204‑1 standard, fitted with a protective cover for safe wiring.
- Cooling System: Natural air cooling via housing cooling fins; forced air cooling fan can be added if required.
4. Typical Application Fields
- Pumping Stations: Drive for self-priming pumps, centrifugal pumps and screw pumps.
- Fans & Blowers: Main drive for industrial ventilation and air conditioning systems.
- Compressors: Direct drive for screw compressors and piston compressors.
- Conveying Systems: Power source for belt conveyors and screw conveyors.
- Processing Machinery: Equipment requiring constant speed, such as punching machines, sawing machines and packaging machinery.
5. Installation & Maintenance Guidelines
- On-site Inspection: Confirm the foundation platform is level, and the fixing bolt holes match the motor flange dimensions.
- Axis Alignment: Use a laser level or micrometer to ensure coaxiality between motor shaft and drive shaft before installation, with alignment error ≤ 0.1 mm.
- Electrical Wiring: Follow IEC 60204‑1 standards; use copper bars or terminals matching the rated current in the terminal box, with grounding resistance ≤ 0.5 Ω.
- Lubrication Maintenance: Check bearing grease every 2000 operating hours (or 12 months) and replace if necessary.
- Temperature Monitoring: Monitor stator temperature during operation; temperature rise should not exceed 55 °C. If exceeded, check ventilation or install forced air cooling.
- Vibration Detection: Conduct full-frequency vibration testing with a handheld vibrometer every 6 months. Shut down immediately for inspection if abnormal vibration ≥ 4.5 mm/s (check rotor balance or bearing wear).
- Regular Cleaning: Keep the housing surface clean to avoid dust blocking cooling fins; clean with a soft brush or low-pressure air when needed.
————————————————————————————————-
