Schneider AEG 92-00757-02

Schneider AEG 92-00757-02 is an HMI (Human-Machine Interface) panel belonging to the PanelMate Plus series (model: MM-PM10-200). It is designed for local display, control, and parameter setting in integration with PLC systems. Compatible with Modicon AEG series controllers, this panel is widely deployed in industrial automation field for real-time monitoring and operational control.

Key Specifications

• Display Screen: 10-inch color TFT with a resolution of 800 × 480 pixels
• Power Supply: DC 18–30 V (24 V optional)
• Communication Interfaces:Input/Output: No on-board field I/O; data exchange is primarily achieved via communication with the host PLC
  • Ethernet 10/100 Mbps (supports Modbus TCP, Ethernet/IP)
  • RS-485 (Modbus RTU)
  • USB Host/Device, CAN, Profibus DP (optional)
• Operating Temperature: -25 °C to +70 °C (industrial-grade)
• Protection Class: IP20 (for indoor use only)
• Dimensions: Approximately 260 mm × 180 mm × 70 mm (including mounting bracket)
• Weight: Around 1.2 kg

Structure & Components

• Front Panel: Touch screen display, function keys (including Back, Home, Emergency Stop, etc.)
• Rear Connectors: Power terminals, Ethernet RJ45 port, RS-485 port, USB ports, optional CAN/Profibus interfaces
• Internal Modules: Power module, main control MCU, communication chip, flash memory
• Mounting Bracket/Holes: Suitable for DIN rail or panel mounting

Typical Application Areas

• Manufacturing Industry: Local monitoring and control of assembly lines, packaging machines, and CNC machine tools
• Process Industry: Process parameter display and alarm systems in chemical, petroleum, food and beverage sectors
• Energy & Power: Status monitoring of generator sets and power distribution cabinets
• Building Automation: On-site HMI for HVAC and lighting control systems
• Logistics & Warehousing: Operation panel for conveyor systems and automatic stackers

Installation & Maintenance Guidelines

• Installation Location: Install in a dry, well-ventilated indoor environment. Avoid direct exposure to strong sunlight or high-temperature heat sources.
• Power Wiring: Comply with DC 18–30 V power supply specifications. Use well-protected terminals and ensure correct polarity connection.
• Communication Cabling: Adopt shielded twisted-pair cables (Cat5e or above) for Ethernet connections. Use differential pairs with terminal resistors for RS-485 communication.
• Grounding & Lightning Protection: Ensure reliable grounding of the panel’s metal casing. Install surge protectors on power lines when necessary.
• Software Configuration: Create HMI projects with EcoStruxure Operator Terminal Designer software, then download the projects to the panel via USB or Ethernet.
• Regular Inspection: Conduct checks every 6 months on touch screen sensitivity, interface tightness, and power supply voltage stability. Replace aging cables or modules promptly.
