Schneider AEG 91-00911-05 Low Voltage Switchgear Cabinet

91-00911-05 belongs to the MM-FMC (Modular-Mounted Compact) series of Schneider AEG, which is a modular compact low-voltage switchgear.

Schneider AEG 91-00911-05

1. Product Overview

91-00911-05 belongs to the MM-FMC (Modular-Mounted Compact) series of Schneider AEG, which is a modular compact low-voltage switchgear. Specifically designed for 400V/690V three-phase four-wire power distribution systems, this model features high-density layout, flexible expansion and quick on-site assembly.

2. Main Technical Parameters

Parameter	Typical Value
Rated Voltage	400V / 690V AC
Rated Current	630A (400A, 800A optional)
Short-Circuit Breaking Capacity	35kA (IEC 60947-2)
Structure Type	Modular, Rear-Mounted Busbar (MLS)
Protection Class	IP20 (Indoor Use)
Ambient Temperature Range	-25°C ~ +55°C
Weight	Approx. 250kg (subject to configuration)
Compliance Standards	IEC 60947-4-1, IEC 61439-1/2

3. Product Features

Modular Design: All functional units (circuit breakers, contactors, relays, measuring instruments, etc.) are standardized modules, enabling quick on-site assembly or replacement and significantly shortening the construction period.
Rear-Mounted Busbar (MLS) Structure: Busbars are arranged at the rear of the cabinet, facilitating maintenance, reducing electromagnetic interference and providing better heat dissipation space.
High Reliability: Adopts low-voltage switching components compliant with IEC 60947-4-1, with multiple protection functions including short-circuit, overload, under-voltage and under-current protection.
Flexible Expansion: Modules can be added or reduced according to load requirements, realizing multi-level applications from main power distribution to sub-distribution.
Compact Size: Smaller in volume and lighter in weight compared with traditional low-voltage switchgears, ideal for projects with limited space.

4. Structure & Composition

Cabinet Body: Welded with high-strength steel plates, with reserved module installation slots inside.
Rear-Mounted Busbar (MLS): Copper or aluminum busbars equipped with quick-connect buckles.
Functional Modules: Including circuit breaker modules, contactor modules, relay modules, measuring instrument modules, communication modules, etc. Each module is configured with standardized terminals.
Power Distribution Terminal Blocks: For external cable access, supporting screw or spring crimping.
Protection Doors & Panels: Optional protection doors with indicator lights and operation buttons to meet on-site operation needs.

5. Typical Application Fields

Industrial Plants: Main power distribution, sub-distribution and power supply for machinery and equipment.
Commercial Buildings: Building power distribution, lighting and air conditioning system power supply.
Energy Stations: Power distribution and control of photovoltaic, wind power and energy storage systems.
Public Facilities: Places with high reliability requirements such as hospitals, schools and data centers.

6. Key Installation & Maintenance Points

Installation

On-Site Survey: Confirm the space, ventilation and grounding conditions of the cabinet installation location.
Foundation & Support: Reserve a solid ground foundation according to the cabinet weight, and use shock pads if necessary.
Busbar Connection: Adopt dedicated quick buckles for rear-mounted busbar connection to ensure firmness and reliability.
Module Assembly: Insert functional modules in sequence according to design drawings, and check whether slot buckles are in place.
Wiring Inspection: All cable terminals must use compliant crimping or screw wiring to ensure good contact.
Commissioning Test: Conduct insulation resistance and grounding continuity tests before power-on; perform short-circuit and overload protection function tests after power-on.

————————————————————————————————-
