Schneider AEG 206/AS-BADU-20

1. Product Overview

2. Key Specifications

• Rated Voltage: Available in 6kV, 12kV or 35kV versions to meet diverse power distribution requirements
• Rated Current: Ranges from 125A to 800A depending on specific models and application scenarios
• Rated Short-Circuit Breaking Capacity: High short-circuit withstand capacity of 25kA to 50kA, ensuring operational safety under fault conditions
• Operating Temperature Range: -25℃ to +55℃, suitable for harsh industrial environments
• Protection Grade: IP3X or IP4X, featuring excellent dustproof and waterproof performance with high protection level

3. Product Features

• Modular Design: Adopts detachable structure for easy on-site installation, maintenance and component replacement, minimizing downtime effectively
• High Reliability: Selected high-quality conductors, terminals and protection devices ensure stable operation in high-voltage environments
• Intelligent Integration: Equipped with communication modules (e.g., Modbus, Profibus, Ethernet) as standard, supporting connection with SCADA and DCS systems to realize remote monitoring and diagnosis
• Compact Structure: More compact size compared with traditional high-voltage cabinets, saving installation space significantly

4. Structure & Components

• Main Busbar System: Uses high-conductivity busbar materials with fixing clamps to ensure firmness and low resistance
• Power Distribution Components: Includes key elements such as air circuit breakers, load switches, fuses and contactors
• Protection Devices: Equipped with overcurrent protection, differential protection and grounding protection devices to guarantee system security
• Auxiliary Systems: Comprises control panels, signal panels, lighting fixtures and temperature monitoring instruments
• Cable Distributors: Built-in dedicated cable channels and distributors to ensure neat wiring and reliable protection

5. Application Fields

• Industrial Power Distribution: Main distribution cabinets for large factories and production lines, undertaking power distribution and control tasks
• Power Systems: Distribution control units for power distribution networks and substations
• Automation Control: Network connection with PLC/RTU to achieve automatic control of industrial sites
• High-Rise Buildings: Centralized power supply and distribution systems for large office buildings and shopping malls
