Schneider AEG 15A0176-000 Distribution Cabinet Panel

Schneider AEG 15A0176-000

1. Product Overview

Schneider AEG 15A0176-000 belongs to the AEG series panel products of Schneider Electric. This model generally refers to a standardized panel integrated with multiple electrical functions such as relays, circuit breakers, and measuring instruments. As an indispensable core component in electrical systems, it is dedicated to centralized control and monitoring of power distribution and consumption.

2. Key Technical Parameters

Rated Voltage: Supports 230V/400V AC power input.Rated Current: The panel is designed to support a current range from several amperes to hundreds of amperes, subject to the configuration of internal modules.Protection Grade: Generally compliant with IP20 standard, suitable for indoor installation environments.Temperature Range: The applicable ambient temperature of the panel is usually between -25°C and +40°C.

3. Product Features

Modular Design: Each functional unit (e.g., circuit breaker, contactor, relay, measuring instrument) is a standardized module, supporting rapid on-site assembly or replacement and significantly shortening the construction period.Rear-mounted Busbar Structure: The busbar is located at the rear of the cabinet, facilitating maintenance, reducing electromagnetic interference, and providing better heat dissipation space.High Reliability: Equipped with low-voltage switching components compliant with IEC 60947‑4‑1 standard, it provides multiple protection functions including short circuit, overload, undervoltage and undercurrent protection.

4. Structure & Composition

Cabinet Body: Made of impact-resistant and corrosion-resistant materials, it usually adopts standardized dimensions for easy installation in distribution cabinets.Functional Modules (including but not limited to):

Circuit Breaker: For circuit overload protection.
Contactor: For circuit on-off control.
Relay: For protection and control functions.
Measuring Instrument: For real-time monitoring of electrical energy parameters.Cable Entries: Provide holes for cable penetration, equipped with seals for dust and moisture prevention.

5. Application Fields

As a core component of electrical distribution systems, this panel is widely used in the following scenarios:

Industrial Automation: Main distribution and control cabinets in factories and workshops.
Building Electricals: Building automation systems and power distribution systems.
Power Facilities: Distribution transformer boxes and distribution stations.
Energy Management: Power control and monitoring in new energy power stations (e.g., photovoltaic and wind power stations).

6. Installation & Maintenance

Benefiting from standardized design, the panel has the following advantages in installation and maintenance:On-site Assembly: The modular design enables rapid on-site assembly; maintenance personnel only need to replace faulty modules without changing the entire panel.Easy Maintenance: The rear-mounted busbar structure simplifies the troubleshooting of internal wiring and connections.Protection Measures: During installation, ensure the panel is firmly fixed and terminal blocks are tightly connected to avoid loosening caused by vibration.Regular Inspection: It is recommended to regularly check the connection status of modules and tightness of terminal blocks to ensure safe operation of the system.

————————————————————————————————-
