Schneider AEG 120-088-002
1. Overview
Schneider AEG 120-088-002 (MM-FMC3-010) is a modular low-voltage distribution cabinet or switchgear. It integrates medium-voltage switchgear (e.g., vacuum switches), low-voltage distribution components (e.g., circuit breakers), and automation control systems (e.g., PLC and HMI) into one unit. This product is designed to deliver an efficient, reliable and easy-to-maintain power distribution solution for industrial scenarios.
2. Specifications
Rated Voltage: 10kV typically (derived from model MM-FMC3-010, compliant with medium-voltage distribution requirements)Rated Current: Supports high current capacity, specific value depends on the selection of internal distribution units (e.g., 1250A, 1600A, etc.)Rated Power: Around 15MVA in generalRated Short-Circuit Current: Features ultra-high short-circuit withstand capacity, suitable for industrial applications with high reliability demandsProtection Class: IP54, dustproof and waterproof, applicable to both indoor and outdoor environments
3. Product Features
Modular Design: Adopts a modular structure for quick assembly, disassembly and maintenance. Internal components (such as vacuum switches and circuit breakers) can be replaced independently, reducing maintenance costs effectively.High-performance Switch Technology: Equipped with AEG vacuum switches, boasting high breaking capacity and low maintenance requirements for long-term stable operation.Intelligent Control: Integrated with PLC (Programmable Logic Controller) and HMI (Human-Machine Interface), supporting remote monitoring and automated control to optimize operation efficiency.Excellent Heat Dissipation: Built-in efficient heat dissipation system ensures stable performance even under high-current loads.Durable & Robust: Made of high-strength materials with anti-corrosion coating, featuring moisture and corrosion resistance, ideal for harsh working environments.
4. Structure & Components
Enclosure: IP54 protection class with sturdy metal structure, providing comprehensive electrical and mechanical protection for internal parts.Main Switch Component: Integrated with AEG vacuum switch inside, responsible for main power switching and protection.Auxiliary Switch Components: Including circuit breakers (for branch circuit protection) and relays, etc.Automation & Communication Modules: Equipped with PLC controller, HMI display and communication gateway, compatible with fieldbus and remote communication protocols.Cables & Busbars: Designed with rear-mounted busbars and efficient cable management system for neat wiring and easy maintenance.
5. Application Fields
This product is widely used in scenarios requiring high reliability and intelligent management:Industrial Plant Power Distribution: Serves as the main distribution cabinet for power distribution and control in large-scale factories.Smart Building Power Distribution: Applied to multi-loop distribution and secondary control, compatible with PLC, HMI and communication gateways.Energy Stations (Solar PV & Wind Power): Connects inverters to the grid with power factor adjustment capability.Data Centers: Offers redundant design and low-noise operation environment to ensure uninterrupted power supply.Marine Power Distribution: With corrosion and moisture resistance, suitable for marine working environments.
6. Installation & Maintenance
Installation: Benefiting from its modular structure, it can be assembled with suitable modules according to on-site requirements. Normally installed in dedicated electrical distribution rooms with sufficient ventilation for heat dissipation.Maintenance: Adopts rear-mounted busbar design, enabling hot-swappable maintenance without cutting off the main power supply. Modular components can be replaced quickly to minimize downtime.Inspection: Regularly check the sealing status and contact wear of vacuum switches to ensure sufficient withstand voltage and breaking capacity.
————————————————————————————————-
