Schneider AEG 120-085-001

Schneider AEG 120-085-001 is a modular low-voltage distribution cabinet designed for industrial low-voltage power distribution. Adopting a Rear Mounted Busbar (MLS) structure, it is compatible with low-voltage switching components compliant with IEC 60947-4-1 standard, offering multiple functional units including circuit breakers, contactors, relays and measuring instruments. It supports on-site quick assembly or replacement, significantly shortening the construction cycle.

Key Technical Specifications

Product Features

1. Modular Design: All functional units (circuit breakers, contactors, relays, measuring instruments, etc.) are standardized modules, enabling free combination or quick replacement on-site as per requirements.
2. Rear Mounted Busbar Structure: Busbars are located at the rear of the cabinet, facilitating maintenance, reducing electromagnetic interference and providing better heat dissipation space.
3. High Reliability: Equipped with low-voltage switching components meeting IEC 60947-4-1 standard, it features multiple protection functions against short circuit, overload, undervoltage and undercurrent.
4. Compact & Flexible: Compact overall size fits various cabinet layouts; modularity supports later-stage function expansion.
5. Easy Installation: Standardized terminals and pre-assembled busbar system greatly reduce wiring workload and improve on-site construction efficiency.

Structure & Components

• Cabinet Body: Steel frame for mechanical support and protection
• Rear Mounted Busbar (MLS): Busbar at the cabinet rear, carrying the main current path
• Functional Modules: Plug-and-play modules including circuit breaker, contactor, relay and measuring instrument modules, configurable per project needs
• Terminal Blocks: Standardized terminals for convenient on-site wiring
• Cooling & Heat Dissipation Device: Natural ventilation or optional fans to ensure components operate within rated temperature range
