1. Overview

2. Specification Parameters

• Measurement Type: Energy Meter
• Ambient Operating Temperature: -25℃ to 70℃
• Ambient Storage Temperature: -40℃ to 85℃
• Display Type: Digital Display
• Protection Level: Complies with NEMA 4/4X/13 Standards (dust-proof, water-proof, chemical corrosion-resistant)
• Dimensions: Height 6.8 cm, Width 8.0 cm, Length 21.5 cm
• Weight: Approximately 347 grams
• Power Supply Requirement: Usually 24V DC power supply
• Communication Interface: Supports MODBUS/RS485 Communication
• Product Code: ZB6AE1
• Warranty Period: 18 Months

_______________________________________________________________________________________________________

3. Product Features

• High-Precision Measurement: Adopts high-precision measurement chip to ensure the accuracy of electrical energy data.
• Multi-Functional Display: Supports local digital display, which can intuitively show key parameters such as voltage, current, and power.
• Remote Monitoring: Through the MODBUS protocol, data can be uploaded to the upper computer to realize remote monitoring and management.
• Industrial-Grade Design: With IP65 protection level, it is suitable for harsh industrial environments.

_______________________________________________________________________________________________________

4. Structure and Composition

• Meter Main Body: Includes LCD display, key panel and internal circuit board of the meter.
• Mounting Bracket: Usually equipped with a mounting bracket or adapter for easy embedded or wall-mounted installation.
• Terminal Blocks: Terminal blocks for power lines and load lines.
• Communication Interface: RS485 interface for connecting to the upper computer.

_______________________________________________________________________________________________________

5. Application Fields

• Industrial Automation: Used to monitor the electrical energy consumption of factory workshops.
• Power Distribution System: Used for electrical energy measurement in substations or power distribution cabinets.
• Building Management: Used for electrical energy monitoring in building automation systems.

_______________________________________________________________________________________________________

6. Installation and Maintenance

Installation

• Environmental Requirements: Ensure that the installation environment meets the IP65 protection level, and avoid exposure to corrosive gases or high-temperature environments.
• Wiring: Correctly connect the power lines and load lines, and ensure the correct direction of the Current Transformer (CT).
• Communication Connection: If using the remote monitoring function, it is necessary to connect the RS485 bus and set the correct baud rate.

Maintenance

• Regular Calibration: To ensure measurement accuracy, regular calibration is recommended.
• Cleaning: Keep the surface of the meter clean to prevent dust from affecting heat dissipation.
• Fault Indication: The meter itself is usually equipped with a fault indicator light. If a fault occurs, it can be diagnosed through the error code on the display or the indicator light.
