Product Type:Module

Product ID:140ESI06210

Schneider Type Designation:Module

Automation Platform:Modicon Quantum

Module Category:ASCII Serial Link

Ports:2

RS232C Interface:Non-isolated

Conforms to DIN 66020:

Electrical Connection:2 x SUB-D 9 Connectors

Power Dissipation (W):4

Product Weight:0.66 lb (US) / 0.3 kg

Number of Ports:2

Communication Rate (Mbit/s):

I/O Words:

Analogue Input Number:

Filter Type:Single Pole Low Pass – 3 dB at 847 Hz

Analog Input Range:

Dissipation in W:2.2

Module Type:Discrete I/O

Head-End Adaptor:

Transmission Rate (Mbit/s):

I/O Words/Drops:

Bus Current Requirement:750 mA

Slots:10, 16, 2, 4, 6

Racks:2 – Local rack(s)

Distributed I/O Stations:63 station(s) – 1 rack(s) – 1 Modbus Plus network(s)

    This Schneider Quantum module is specifically tailored for the Modicon Quantum automation platform, ensuring reliable and high-speed communication capabilities.

    Featuring two RS232C ports, it supports the efficient transfer of ASCII serial data, making it ideal for various industrial control applications.

    Compliant with the stringent DIN 66020 standard, the module ensures compatibility and safety in diverse industrial environments.

    With its 2 connectors designed for SUB-D 9 interfaces, it simplifies the setup process and ensures easy integration with existing hardware.

    The module’s power dissipation of ≤ 2 W makes it energy-efficient, suitable for systems where power consumption is a concern.

    Compact and lightweight, weighing just 0.66 lb (US) (0.3 kg), this module is easily integrated without adding unnecessary bulk to your system.
