Schneider 140CPU67160S
Overview
The Schneider 140CPU67160S is a Unity Hot Standby processor module specifically designed for industrial automation and process control. It features high reliability and redundancy capabilities—even if the main processor fails, the backup processor can take over immediately, ensuring continuous system operation and greatly reducing downtime.
_______________________________________________________________________________________________________
Core Specifications
|
Specification
|
Typical Value/Description
|
|---|---|
|
Model
|
140CPU67160S
|
|
Series
|
Modicon Quantum / M580e
|
|
Processor Type
|
PowerPC 603e (Unity Processor)
|
|
Clock Speed
|
266 MHz
|
|
Memory
|
4 MB RAM (some versions)
|
|
Flash
|
4 MB Flash (some versions)
|
|
Input Voltage
|
24V DC (typical)
|
|
Communication Interfaces
|
RJ45 Ethernet, Modbus, Modbus Plus, USB, Fiber Optic (MT-RJ)
|
|
I/O Points
|
Supports up to 256 points (depending on configuration)
|
|
Operating Temperature
|
-20℃ – +60℃ (some models -40℃ – +70℃)
|
|
Dimensions
|
12.80 x 15.30 x 5.20 cm (some models 190 x 100 x 30 mm)
|
|
Weight
|
Approx. 0.5 kg – 0.8 kg
|
_______________________________________________________________________________________________________
Product Features
Unity Hot Standby Redundancy
Adopting a dual-slot design, it has a built-in main processor and backup coprocessor. In case of a failure, the system will automatically switch to the backup processor to ensure no interruption of critical processes.
Powerful Computing Capability
Equipped with a 266 MHz PowerPC processor, along with large-capacity RAM and Flash, it can quickly process large amounts of data and complex control logic.
Rich Communication Interfaces
Supports multiple industrial communication protocols (Modbus, Modbus Plus, Ethernet, USB, Fiber), facilitating integration with various on-site devices and upper-level computer systems.
_______________________________________________________________________________________________________
User-Friendly Human-Machine Interface
The front panel is equipped with an LCD display (two lines of 16 characters), LED indicators (such as Ready, Run, Error, etc.), and a 5-key keyboard, making on-site operation and fault diagnosis convenient.
Strong Expandability
Supports a memory expansion slot, allowing users to expand storage capacity according to actual needs.
Structure and Composition
- CPU Processor Unit: The main control core, responsible for executing logic control programs.
- Backup Coprocessor: Provides redundancy support to ensure high system availability.
- Power Supply Module: Provides 24V DC power input; some models are equipped with a backup battery slot.
- Communication Interface Module: Includes RJ45 interface, USB interface, fiber optic interface, etc.
- Indicator Panel: Contains various status indicators for monitoring system operation status.
————————————————————————————————-
