Schneider 140CPU11303C
1. Overview
Schneider 140CPU11303C is a core processor in the Modicon Quantum series PLC of Schneider Electric. This model is specially designed for high-performance industrial automation, with powerful computing capability and rich communication interfaces, which can meet the needs of complex control systems.
_______________________________________________________________________________________________________
2. Specifications
|
Specification
|
Description
|
|---|---|
|
Model
|
140CPU11303C
|
|
CPU Core
|
Unity Processor (486 level)
|
|
Clock Speed
|
66 MHz
|
|
SRAM
|
512 KB
|
|
Flash
|
368 KB (Program Storage)
|
|
IEC Storage
|
10,000 Points
|
|
Register Storage
|
10,000 Points
|
|
Memory
|
1 MB (Expandable to 1 MB+)
|
|
Communication Interfaces
|
1 Modbus RS232, 1 Modbus Plus, 1 Ethernet Port
|
|
Supply Voltage
|
24 VDC (Depends on the selected power module)
|
|
Protection Level
|
IP20 (Must be installed in a chassis)
|
_______________________________________________________________________________________________________
3. Product Features
- High-Performance Computing: Equipped with a 486-level Unity processor with a clock speed of up to 66 MHz, it has strong processing capability and is suitable for harsh industrial environments.
- Large Storage Capacity: With 512 KB SRAM and 368 KB Flash, it can store more IEC code and data, supporting more complex control logic.
- Rich Communication Capability: Built-in Modbus RS232, Modbus Plus and Ethernet interfaces, supporting a variety of field buses and network protocols, facilitating data exchange with upper computers or other devices.
- Modular Design: Supports a variety of I/O expansion modules (analog, digital, special function modules, etc.), making it easy to flexibly configure the system according to actual needs.
- High Reliability: Available in a Coating version, which can operate stably for a long time in humid and corrosive environments.
_______________________________________________________________________________________________________
4. Structure and Composition
- CPU Module Body: The core processing unit, including CPU, memory, communication interfaces and power supply interface.
- Chassis: Usually installed in 140XBP or 140DAO series chassis, providing power supply and physical support.
- Power Module: Provides power for the CPU and expansion modules, usually 140XBP series power supply.
- Communication Card: If additional network interfaces (such as Profibus, DeviceNet) are needed, a dedicated communication card can be installed.
_______________________________________________________________________________________________________
5. Application Fields
- Manufacturing Automation: Production line control, packaging machinery, robot control systems.
- Process Industry: Process control and monitoring in chemical, petrochemical and pharmaceutical industries.
- Energy Industry: Control and protection of power systems and power plants.
- Infrastructure: Comprehensive management of water supply and drainage, heating, ventilation and air conditioning systems.
————————————————————————————————-
