Schneider 140CHS32000
1. Overview
The Schneider 140CHS32000 is a high-capacity PLC belonging to the Quantum 140 series, equipped with robust processing capabilities and abundant communication interfaces. Adopting a modular design, it can flexibly adapt to control requirements of different scales, serving as a core control device in industrial automation, process control, energy management and other industrial fields.
_______________________________________________________________________________________________________
2. Technical Parameters
|
Parameter Type
|
Specific Value/Specification
|
|---|---|
|
CPU Series
|
Quantum 140
|
|
Model
|
140CHS32000 (Also known as BMEP582020H)
|
|
Module Dimensions
|
100mm x 100mm (10.0cm x 10.0cm)
|
|
Maximum Expansion Slots
|
6 slots (Including the CPU slot)
|
|
CPU Slot Quantity
|
1 slot (The CPU slot occupies one slot independently)
|
|
CPU Model
|
BMEP582020H
|
|
Maximum Discrete I/O (DI/DO)
|
Approximately 2000 points (Subject to the configuration of expansion modules)
|
|
Analog I/O (AI/AO)
|
Determined by expansion modules (Supports various analog modules)
|
|
Communication Interfaces
|
Supports multiple fieldbuses and industrial networks including Ethernet/IP, Modbus TCP, CANopen, Profibus DP, Profinet, CC-Link, DeviceNet (Realized via expansion modules)
|
|
Programming Software
|
Unity Pro (Renamed as EcoStruxure Control Expert)
|
|
Operating Temperature
|
-25°C to 70°C (Subject to specific models, complying with industrial-grade standards)
|
|
Power Supply
|
Generally 24V DC (To be confirmed according to specific module models)
|
_______________________________________________________________________________________________________
3. Key Features
- High-Performance CPU: Adopts the latest processor architecture, delivering powerful logic processing capabilities to quickly execute complex programs such as ladder diagrams and structured text, ensuring efficient and stable operation of industrial control systems.
- Modular Structure: Supports hot-swappable function, greatly simplifying equipment maintenance and replacement. Users can select different types of I/O modules for flexible expansion based on actual on-site control needs, realizing customized control solutions.
- Abundant Communication Capabilities: Built-in multiple industrial-standard communication protocols, enabling seamless integration with upper systems (SCADA, MES) and field devices. It realizes efficient data transmission and interconnection, building a unified and efficient industrial control network.
- High Security Performance: Supports the expansion of hot standby redundancy and safety modules, fully meeting the application requirements of high safety integrity level (SIL), and providing reliable safety guarantee for key industrial scenarios with high safety demands.
- Convenient Programming: Compatible with programs of old-version Schneider PLCs, supporting multiple programming languages including ladder diagram, function block diagram and structured text, lowering the threshold for programming, debugging and program migration.
_______________________________________________________________________________________________________
4. Structure and Components
- CPU Module (BMEP582020H): As the core of the control system, it undertakes key tasks such as program execution, logic operation, data processing and communication management, and is the “brain” of the entire PLC control system.
- Power Supply Module: Provides stable power supply for the CPU module and all expansion modules, with a conventional rated voltage of 24V DC, ensuring stable and reliable power input for the whole equipment under industrial operating environments.
- Expansion I/O Modules: Covers a full range of modules including digital input (DI), digital output (DO), analog input (AI) and analog output (AO), meeting the access needs of various digital and analog signals in industrial sites.
- Communication Module: Used to connect fieldbuses (such as Profibus, Profinet, CANopen) or industrial Ethernet networks (Ethernet/IP, Modbus TCP), realizing data interaction between the PLC and peripheral equipment and upper systems.
- Rack: Serves as the physical support structure for installing all modules, with standard slot design to ensure stable installation and fixed connection of CPU, power supply, I/O and communication modules.
_______________________________________________________________________________________________________
5. Application Fields
The Schneider 140CHS32000 PLC features stable performance and strong scalability, and is widely applied in high-demand industrial control scenarios, mainly including the following fields:
- Large-Scale Factory Automation: Applied to large-scale production lines such as automobile manufacturing and electronic manufacturing, realizing automated control of assembly, processing and testing links, and improving production efficiency and product consistency.
- Process Control: Suitable for precision process control in industries such as chemical industry, petroleum and food & beverage, realizing accurate adjustment and monitoring of process parameters such as temperature, pressure, flow and liquid level.
- Energy Management: Deployed in power plants, power distribution automation systems and smart grids, assisting in intelligent monitoring, dispatching and management of energy, and improving energy utilization efficiency and power supply reliability.
- Building Automation: Used for comprehensive management of large commercial complexes, data centers and other buildings, realizing centralized control of air conditioning, lighting, power distribution and security systems.
————————————————————————————————-
Main brand
ABB Allen-Bradley Alstom Bently Emerson Foxboro
GE MOOG Schneider Woodward HIMA Honeywel Triconex & more
