Schneider AEG AS-B808-016

The AS-B808-016 is a programmable controller servo server launched by Schneider Electric, belonging to the industrial automation control series. It adopts high-quality electronic components, delivering stable and reliable programming control and servo drive functions in harsh industrial environments. This product is ideal for applications requiring high-precision motion control.

Key Technical Specifications

• Power Supply: 24 V DC (48 V optional)
• Input/Output: Digital I/O, analog input, and communication interfaces (Modbus TCP, Profibus, CANopen)
• Processor: High-speed embedded CPU supporting multi-task real-time operation
• Storage: Built-in Flash memory enabling offline backup of user programs and parameters
• Operating Temperature: -20 °C to +60 °C; Protection Class IP20 (IP65 optional)
• Dimensions: Standard 19-inch rack-mountable, 2U width

Product Features

1. High ReliabilityIndustrial-grade components ensure excellent anti-interference and anti-vibration performance, making it suitable for continuously operating production lines.
2. Multi-protocol CompatibilityIntegrated with a variety of fieldbus and Ethernet protocols, it enables seamless integration with upper-level systems, PLCs, and HMIs.
3. Flexible ProgrammingSupports multiple programming languages including ladder diagram and structured text, complying with the IEC 61131-3 standard.
4. Modular DesignFunction modules support hot swapping, facilitating on-site expansion and maintenance.
5. Diagnosis and MonitoringOffers real-time fault diagnosis, parameter monitoring, and remote upgrade functions.

Structure and Components

• Host Frame: Rack-mountable housing equipped with CPU, storage, and power supply modules.
• I/O Expansion Cards: Digital, analog, or high-speed counting cards can be inserted according to on-site requirements.
• Communication Modules: Optional communication cards such as Ethernet, Profibus, and CANopen.
• Power Supply Unit: Provides regulated DC power with overvoltage and overcurrent protection.
• Heat Dissipation System: Fan or passive heat sink ensures thermal balance during long-term operation.

Typical Application Fields

• Motion control of automated production lines (e.g., packaging and assembly robots)
• Servo drive for CNC machine tool systems
• Regulation of valves and pump stations in process control systems
• Synchronous control of logistics conveying systems
• Energy management and power distribution automation

Installation and Maintenance Guidelines

Installation

Wiring

Commissioning

Daily Maintenance

• Regularly check the operation status of cooling fans and clean accumulated dust.
• Monitor power supply voltage and I/O status, replacing faulty modules promptly.
• Utilize the system’s built-in diagnostic logs for preventive maintenance.
