XYCOM CS8500
Overview
The XYCOM CS8500 is an embedded computing platform designed for industrial control and human-machine interaction (HMI). It supports the Windows XP Professional operating system, making it ideal for applications such as on-site monitoring, data acquisition, and automated control.
Key Specifications
| Parameter | Details |
|---|---|
| Dimensions/Weight | 375 mm × 315 mm × 70 mm, approximately 6.5 kg |
| Operating Environment | Temperature: -10 °C to 50 °C; Storage Temperature: -20 °C to 60 °C; Relative Humidity: 10% – 90% (non-condensing) |
| Power Supply | 24 V DC ± 10%, power consumption: approx. 60 W |
| Protection Rating | Front panel IP65 certified |
Product Features
- Rich Industrial Interfaces: Equipped with VGA, RS-232/RS-422/485, 10/100 Mbps Ethernet, USB 2.0, and audio I/O ports, enabling seamless integration with diverse industrial devices.
- Rugged & Certified Design: Features a resistive touchscreen and complies with CE and FCC Class A standards, ensuring robust anti-interference performance for stable operation in harsh industrial environments.
- Flexible Installation Options: Supports both desktop and panel-mount configurations, allowing for agile deployment in on-site scenarios.
Structure & Components
- Chassis: Constructed with metal or high-strength plastic and fitted with protective sealing rings, achieving IP65 front-panel protection to resist dust and water ingress.
- Internal Modules: Core components including the motherboard, I/O expansion cards, heat dissipation system, and power supply module all adopt industrial-grade components, guaranteeing long-term reliable operation.
- Keyboard/Panel Components (e.g., XYCOM 97788-003): Built with plug-and-play standardized interfaces. Keycaps, PCBs, and enclosures are moisture-proof, facilitating quick on-site replacement when needed.
Application Areas
The XYCOM CS8500 is widely applicable in scenarios requiring environmental resilience and reliable communication, such as:
- Industrial automation control stations
- On-site monitoring terminals
- Machine vision frontends
- Logistics sorting systems
- Energy management platforms
Installation & Maintenance
Installation Method
Choose between desktop placement or panel embedding. The package includes matching screws and fixtures, eliminating the need for professional tools during installation.
Maintenance Tips
- Regularly inspect the power supply and heat dissipation channels to ensure dust-proof and moisture-proof integrity of all interfaces.
- Thanks to the plug-and-play design of modules like the keyboard and front panel, faulty parts can be replaced rapidly, minimizing equipment downtime.
————————————————————————————————-
