Operating Range:0 to 100 PSI

Accuracy:+/- 1% of full scale

Switching Points:Adjustable

Power Supply:12 to 24V DC

Contact Rating:10A at 250V AC or 16A at 24V DC

Relay Type:SPST

Enclosure Type:IP65

Material:Stainless Steel

Temperature Range:-40°F to 185°F

    The United Electric H100-171 Pressure Switch / Diaphragm boasts an innovative design that ensures precise and consistent monitoring of fluid pressure, making it ideal for demanding industrial environments.

    Equipped with a durable stainless steel housing and brass components, this switch offers exceptional corrosion resistance and reliability, ensuring long-lasting performance even in harsh conditions.

    Featuring a snap action mechanism, the H100-171 provides immediate response to pressure changes, enabling quick and accurate control in applications requiring prompt feedback.

    With adjustable switching points from 80 to 90 PSI, users can customize the device to meet specific operational requirements, offering flexibility across different industrial sectors.

    The switch’s SPDT contact configuration supports both ON/OFF and ON/OFF/ON functionality, providing versatile integration options for a wide range of control systems.

    Certified to IP65 standards, the H100-171 is protected against dust and water ingress, ensuring reliable operation in outdoor or dusty industrial settings.
