1. Overview
UNIOP ETOP507U3P3 This product is a compact 4.3-inch wide-screen color touch panel, positioned as a high-cost-performance and uncompromising low-cost solution while retaining the advanced functions and excellent performance of the eTOP500 series. Supporting the JMobile runtime environment, it serves as an ideal display and control terminal for small-scale industrial automation applications.
2. Main Specifications
|
Item
|
Specification
|
|---|---|
|
Display Screen
|
4.3-inch TFT color LCD with LED backlight and full-color display
|
|
Resolution
|
4.3-inch wide screen (Official pixel values not explicitly released; the conventional resolution for screens of the same size is 480×272)
|
|
Processor
|
ARM Cortex-A8 with a main frequency of 600 MHz
|
|
Ethernet Interface
|
Dual 100Mb Ethernet ports with built-in switch function
|
|
Other Interfaces
|
USB, serial ports (RS-232/RS-485, etc.), MPI (Multi-Point Interface)
|
|
Integrated Expansion Slot
|
Optional pluggable fieldbus/network module
|
|
Storage Expansion
|
SD card support
|
|
Software Platform
|
Supports JMobile Studio development environment; optional integrated IEC 61131-3 soft PLC (CODESYS V2/V3)
|
|
Warranty
|
5-year warranty
|
3. Product Features
High-Performance Core: Equipped with an ARM Cortex-A8 600 MHz processor, it delivers smooth human-machine interaction responses.
Dual Ethernet Port Design: Built with two 100Mb Ethernet ports and an integrated switch, it simplifies network wiring and adapts to interconnection of small-scale equipment.
Full-Metal Housing: Adopting innovative mechanical design and an all-metal body, it enhances durability and anti-interference capability.
Comprehensive Protection: All electronic boards are coated with protective materials to adapt to harsh industrial field environments.
Versatile Communication Capabilities: Integrated with Ethernet, USB, serial ports and MPI interfaces, and compatible with optional fieldbus expansion modules. The gateway function supports remote deployment and technical assistance.
Integratable Soft PLC: Optional built-in CODESYS soft PLC compliant with the IEC 61131-3 standard realizes integrated HMI and control functions.
Multi-Color Front Panel Options: Standard black front panel model (U3P1), with optional white (U1P1) and silver (U2P1) versions available.
4. Structure and Composition
The hardware structure of the eTOP504 includes the following components:
-
Power Supply Interface
-
Serial Port
-
Dual Ethernet Ports
-
USB Port
-
Expansion Slot for Plugin Modules
-
SD Card Slot
Featuring a compact overall structure and an all-metal enclosure, the product is fitted with a black plastic/metal border on the front panel.
5. Application Fields
The eTOP504 is widely applied in the following industrial automation scenarios:
-
Human-machine interface for small mechanical equipment
-
Data monitoring and collection on industrial sites
-
Remote equipment diagnosis and maintenance
-
Display terminal for embedded control systems
-
Applicable to shipping, automotive, oil and gas, construction and other industries with relevant industry certifications
6. Installation and Maintenance
Installation Method: Adopts embedded cutout installation, compatible with dedicated mounting boxes (such as inclined mounting boxes applicable to 1.2mm thick iron sheets).
Front Panel Protection: The front panel features an IP65 protection grade (dustproof and waterproof), suitable for harsh industrial environments.
Maintenance Guidelines:
-
Clean the front panel regularly with a soft dry cloth to wipe the touch screen;
-
Check the tightness of power connections and communication cables periodically;
-
Use an SD card for application program backup and firmware upgrades;
-
PROTOFOIL series protective foils can be applied to the screen surface for scratch resistance and UV protection;
-
For specific installation cutout dimensions and electrical wiring specifications, please refer to the official eTOP504 Tech-Note and JMobile Studio operation manual.
————————————————————————————————-
