UNIOP ETOP507MFB
1. Overview
The UniOP ETOP507MFB is a 15-inch TFT color touch screen Human-Machine Interface (HMI) belonging to the eTOP 500 series, manufactured by Exor International S.p.A. Featuring powerful communication capabilities, this HMI touch panel is well-suited for small-scale industrial applications. As a core model of the eTOP500 series, it integrates advanced functions, high performance and exquisite industrial design, perfectly adapting to demanding HMI application scenarios in industrial environments.
2. Main Specifications
|
Item
|
Specification
|
|---|---|
|
Display Screen
|
15-inch TFT color LED display
|
|
Resolution
|
1024 × 768 pixels
|
|
Display Colors
|
64K colors
|
|
Brightness
|
Adjustable
|
|
Touch Screen
|
Capacitive touch screen (standard configuration of the series)
|
|
User Memory
|
256MB Flash
|
|
Storage Expansion
|
SD card slot
|
|
Serial Port
|
RS-232 / RS-485 / RS-422
|
|
Ethernet Port
|
Dual 10/100 Mbit ports
|
|
USB Port
|
Two ports (USB 2.0 / 1.1 compatible)
|
|
Expansion Slots
|
Two optional expansion slots
|
|
Clock Module
|
Built-in real-time clock with rechargeable battery
|
|
Power Supply Voltage
|
10–32 VDC (18–32 VDC specified in partial official documents)
|
|
Operating Current (24VDC)
|
Approx. 1.4A
|
|
Weight
|
Approx. 3.5 kg
|
3. Product Features
-
Powerful Communication Performance: Equipped with full-range interfaces including RS-232/RS-485/RS-422 serial ports, dual Ethernet ports and USB ports, delivering outstanding and diversified communication capabilities to meet various industrial connection demands.
-
Large-size & High-resolution Display: Adopts a 15-inch display with 1024×768 resolution and 64K color display, presenting clear and delicate industrial screen display effects.
-
Flexible Expandability: Reserved two optional expansion slots, supporting customized function expansion to adapt to diversified industrial application scenarios.
-
Diversified Panel Color Options: Three front panel color versions are available, including white, silver and black, matching different industrial equipment styles and installation environments.
-
Comprehensive Software Support: Compatible with JMobile runtime software. The entire eTOP500 series is equipped with ARM Cortex-A8 processor, and supports multiple industrial communication protocols and report formats, ensuring stable and compatible software operation.
4. Structure and Composition
-
Display Component: 15-inch TFT color LED display with adjustable backlight brightness.
-
Storage Module: Built-in 256MB user Flash memory, equipped with an independent SD card slot for extended storage.
-
Communication Interfaces: Integrated RS-232/RS-485/RS-422 multi-protocol serial ports, dual 10/100 Mbit adaptive Ethernet ports and dual USB 2.0/1.1 compatible ports.
-
Expansion Configuration: Two reserved optional expansion slots for functional upgrade and expansion.
-
Internal Core Devices: Built-in high-precision real-time clock module with rechargeable backup battery to ensure continuous clock operation after power failure.
-
Supporting Accessories: Compatible with PROTOFOIL-15 series disposable protective foils, divided into standard GL type and UV-resistant UV type, with 10 pieces per package.
5. Installation and Maintenance
The installation, transportation, storage, assembly, operation and daily maintenance specifications of the device are specified in the official eTOP500 series operating instructions. Since the complete detailed content of the dedicated eTOP515 manual is not available, it is recommended to refer to the official Exor document eTOP Series 500 Operating Instructions for accurate standard requirements including specific installation dimensions, wiring specifications and panel mounting steps, so as to ensure standardized equipment operation and maintenance.
————————————————————————————————-
