UniOP eTOP507 Control Board Module

UniOP eTOP507

UniOP eTOP507 is a mid-to-high-end model in the eTOP series under EXOR (Italy). As an upgraded version of the UniOP series, it is specifically designed to meet HMI (Human-Machine Interface) requirements in harsh industrial environments. While maintaining the durability and compatibility of the UniOP series, eTOP507 introduces more powerful processing capabilities, richer network functions, and more flexible multi-language support.

_____________________________________________________________________________________________________________

2. Core Specifications

Display: 7-inch (approximately 17.8cm) color display with a resolution of usually 800×480 pixels or higher, wide viewing angle, and high-brightness display support.
Touch Technology: 5-wire or 10-wire Capacitive Touch screen, supporting multi-touch, with high touch sensitivity and wear resistance.
CPU: Adopts a high-performance industrial-grade embedded processor, supporting complex graphical interfaces and fast data processing.
Memory: Built-in 2GB DDR4 RAM, with storage space usually 4GB-8GB (EMMC or SSD), meeting the storage needs of large engineering files.
Communication Interfaces: Equipped with multiple RS-485 interfaces (supporting protocols such as Modbus RTU/ASCII, Profibus DP, CANopen, Ethernet/IP), enabling direct connection to various PLCs (Siemens, Mitsubishi, Omron, Schneider, etc.).
Network Functions: Supports Ethernet 10/100M (Wi-Fi module optional), with basic network diagnosis and remote access functions.

_____________________________________________________________________________________________________________

3. Product Features

Industrial-Grade Durability: Usually reaches IP65 protection level, with dust resistance, water resistance, low-temperature resistance (-25℃) and high-temperature resistance (+60℃) capabilities.
Multi-Language Support: Built-in multi-language library, suitable for multi-language operating environments.
Rich Industrial Protocols: Supports various protocols such as Modbus, Profibus, and CAN, with extremely strong compatibility.
Fast Boot: Adopts an optimized system structure, with fast boot speed and stable operation.
Modular Design: Easy to install and maintain, supporting modular replacement.

_____________________________________________________________________________________________________________

4. Structure and Composition

Panel Main Body: Includes LCD/LED display, touch glass layer, backlight module, and PCB main board.
Chassis: Industrial-grade chassis, usually made of metal or high-strength plastic, with built-in protective sealing ring.
Connection Terminal Block: DIN rail terminal block on the back panel or side panel, used for wiring PLCs and sensors.
Power Module: Internal or external power supply module, providing stable working voltage (usually 24V DC).

_____________________________________________________________________________________________________________

5. Typical Application Areas

Packaging Machinery: Control interfaces for food packaging, bottling, and canning machines.
Machine Tools and Special Machines: CNC machine tools, laser cutting machines, punch presses, etc.
Automation Transformation: Modernization transformation of old machines, replacing traditional button panels.
Logistics Systems: Sorting equipment, conveyor belt control systems.
Textile and Woodworking: Production line monitoring and operation.

————————————————————————————————-
