UNIOP ETOP306U3016
Product Overview
The eTOP50 ETOP306U3016 is 15-inch TFT color touchscreen HMI (Human Machine Interface) panel is professionally engineered for industrial automation scenarios. It belongs to a mature series of industrial operator panels, which is widely applied to machine control, process visualization and industrial monitoring system construction.
Adopting a white front panel design, the industrial HMI panel is equipped with mainstream Ethernet and USB communication interfaces, which can be perfectly integrated into modern industrial automation networks. As a core industrial operator terminal, it supports direct interactive connection with various industrial equipment including PLCs, controllers and drives.
The panel provides an intuitive graphical interactive interface, which can real-time display industrial process data, equipment alarms, operating parameters and machine operating status. Meanwhile, it allows on-site operators to issue remote control commands to complete on-site equipment operation and process adjustment.
Product Specifications
|
Parameter
|
Specification
|
|---|---|
|
Manufacturer
|
UniOP / Exor
|
|
Product Type
|
Industrial HMI Operator Panel
|
|
Display Type
|
TFT Color LCD
|
|
Display Size
|
15 inch
|
|
Resolution
|
1024 × 768 pixels
|
|
Touch Technology
|
Analog Resistive Touchscreen
|
|
Front Panel Color
|
White
|
|
Communication Interfaces
|
Ethernet, USB
|
|
Input Voltage
|
24 VDC (+10% / -15%)
|
|
Backlight Type
|
CCFL
|
|
Operating Temperature
|
0°C to +50°C
|
|
Storage Temperature
|
-20°C to +70°C
|
|
Installation Method
|
Panel Mount
|
As a standard industrial operator panel, the device features a 15-inch TFT color touch display and comes with dual Ethernet and USB communication ports, meeting the basic connection and display needs of most industrial automation scenarios.
Display and HMI Functions
Tailored for complex industrial environments, this HMI panel delivers clear, stable and intuitive human-computer interaction experience. The large-size high-definition TFT display supports detailed presentation of machine operating data, process flow graphics, operation trend charts, alarm information and multi-scene control interfaces, meeting the fine monitoring needs of industrial production.
The core HMI functional modules cover full-process industrial operation and monitoring requirements, including:
-
Real-time process visualization
-
Machine status real-time monitoring
-
Alarm and event record and display
-
On-site parameter adjustment and modification
-
Production recipe management
-
Full-dimensional production data monitoring
-
Manual operator command input
-
Stable PLC data communication
-
On-site industrial equipment diagnostics
Equipped with analog resistive touchscreen technology, the panel supports multi-mode operation including finger touch, gloved hand operation and industrial tool touch. It has strong environmental adaptability, and can maintain stable and sensitive touch response in harsh factory production environments, ensuring reliable human-computer interaction.
Hardware Structure and Communication
The HMI panel adopts an integrated industrial-grade hardware structure, with compact and durable internal components, including TFT LCD display module, high-precision resistive touch interface, embedded HMI main control processing circuit, independent communication interface circuit, stable power supply module and industrial anti-interference mounting enclosure. The overall structure is designed for industrial durability, with strong anti-vibration, anti-interference and dust-proof capabilities.
In terms of communication performance, the built-in Ethernet interface supports high-speed connection to industrial local area networks, realizing data interconnection and remote transmission with upper computer and control system. The USB interface is mainly used for on-site project program transmission, daily equipment maintenance, data backup and peripheral device connection communication.
In the entire industrial automation system, the HMI panel acts as a key communication bridge between operators and field control equipment. The standardized operation logic of “operator – HMI panel – PLC/controller – field equipment” realizes centralized monitoring, unified management and convenient manual control of the entire industrial production process, greatly improving the intelligence of production operation.
Industrial Applications
This industrial HMI panel has wide applicability and can be deployed in various industrial automation and mechanical control scenarios, covering multiple industry fields:
-
Factory integrated automation systems
-
Intelligent packaging machinery
-
Automated production and assembly lines
-
Industrial process control equipment
-
CNC machine tools and processing equipment
-
Material handling and conveying systems
-
Industrial energy management systems
-
Water treatment and environmental protection equipment
-
Industrial testing and detection systems
-
OEM customized automation equipment
Benefiting from the large-size high-definition display screen, the panel is particularly suitable for industrial scenarios that require multi-interface switching, detailed graphic display and massive process data monitoring, and can meet the high-precision and full-information operation and monitoring needs of complex production processes.
Installation and Maintenance
To ensure the stable operation of the equipment, relevant pre-inspection work needs to be completed before installation, including confirming that the 24 VDC power supply is stable and compliant, the panel installation opening size matches the equipment, the grounding connection is standard and reliable, the communication parameters are compatible with the control system, and the supporting HMI project software is complete and normal.
In the process of daily installation, commissioning and later maintenance, the following specifications need to be followed:
-
Disconnect the power supply completely before wiring, plugging and unplugging or disassembling the equipment to avoid electric shock and equipment damage
-
Protect the touchscreen surface from sharp object scratches and excessive external pressure to avoid screen damage and touch failure
-
Regularly check the connection firmness of Ethernet and USB interfaces to ensure stable data transmission
-
Clean the panel surface regularly with professional and compatible cleaning materials to keep the display clear
-
Recheck and calibrate communication parameters after equipment replacement or maintenance to ensure normal system connection
In industrial application environments, avoiding long-term excessive vibration, humid and dusty environments, and operating beyond the specified temperature range can effectively reduce equipment failure rate and prolong the service life of the HMI panel.
Replacement and Lifecycle Support
This series of HMI panels is a key supporting spare part for industrial automation systems. When replacing and updating equipment, it is necessary to confirm the front panel version specifications of the equipment in advance, as the same series of products have different front panel design versions to adapt to different installation scenarios.
To ensure the accuracy of equipment procurement, replacement and maintenance work, relevant supporting information should be provided completely, including product label photos, original HMI project operation data, system communication configuration parameters and supporting mechanical equipment information.
Matching and replacing the standard HMI panel can effectively reduce production downtime, ensure the continuous and stable operation of industrial automation systems, and provide reliable lifecycle operation guarantee for on-site production equipment.
————————————————————————————————-
