UniOp ETOP306U101 Circuit Board Module

UniOp ETOP306U101 is a model in the UniOp series, typically referring to the version equipped with a white front panel (U101). It is a 5.7-inch touch screen panel, mainly used in industrial automation, building automation, and display interaction scenarios requiring high reliability.

UniOp ETOP306U101

1. Overview

_____________________________________________________________________________________________________________

2. Specifications

Display: 5.7-inch TFT LED color display with a resolution of 320×240 QVGA pixels, supporting 64K colors.
Touch Technology: Resistive touch screen, suitable for various industrial environments.
Communication Interfaces: Supports 10/100 Mbit Ethernet interface and USB interface, facilitating data transmission and peripheral connection.
Durability: Usually equipped with industrial-grade features such as high temperature resistance, shock resistance, and dust resistance, suitable for harsh environments.

_____________________________________________________________________________________________________________

3. Product Features

Multi-language Support: Built-in multiple language versions for global use.
Secure Connection: Supports HTML5/JS-based web technologies, with secure connection and real-time data update capabilities.
Customizability: Provides a variety of development tools and programming languages, supports multi-touch and more than 2000 built-in widgets, suitable for complex application requirements.
Appearance: Offers multiple color options such as white, black, and silver, among which U101 represents the white panel.

_____________________________________________________________________________________________________________

4. Structure and Composition

The device is mainly composed of a display module, a touch panel, a circuit mainboard (including a processor and memory), and a housing. The housing is usually made of metal material and has an IP20 protection rating.

5. Application Fields

Industrial Automation: Used for monitoring machine operation status and controlling production processes.
Building Automation: Used for energy management, security systems, etc.
Chemical and Electronics: Suitable for chemical, electronic, metallurgical and other fields requiring reliable monitoring.

_____________________________________________________________________________________________________________

6. Installation and Maintenance

Installation

It is usually fixed on the equipment panel with screws or brackets. During installation, attention should be paid to protective measures to prevent dust and vibration.

Maintenance

It is recommended to regularly clean the surface of the display screen, check the connection status of the interfaces, and keep the working temperature between -10℃ and +60℃.

————————————————————————————————-
