UniOp eTOP30 Touchscreen

UniOp eTOP30 is an industrial-grade Human-Machine Interface (HMI) product launched by Unip Technology. As part of the eTOP series, it is an upgraded version of the traditional small-sized UniOp screens, meeting the visual and operational requirements of mid-to-high-end UniOp models.

UniOp eTOP30

_____________________________________________________________________________________________________________

1. Core Parameters & Specifications

The eTOP30 series is typically equipped with a 7-inch (or similar size) capacitive touch screen, featuring high-resolution display that supports more complex UI interfaces and enhanced communication capabilities.

Parameter	Description
Display Type	VGA (640 × 480 Pixels)
Touch Technology	Capacitive Touch
Brightness	300cd/m²
Contrast Ratio	800:1
Operating Temperature	-10℃ – +60℃
Dimensions	Approx. 200mm × 150mm × 50mm (Specific dimensions vary slightly by model)

2. Product Features

High-Resolution Display: Offers VGA resolution with clear and delicate images, suitable for scenarios requiring fine graphic display.
Powerful Communication Capabilities: Supports multiple communication interfaces such as Ethernet, adapting to modern industrial network requirements.
Industrial Field Reliability: Designed specifically for industrial sites, with high anti-interference performance and stable long-term operation.
Complex UI Support: Suitable for projects requiring higher resolution and more complex user interaction.

_____________________________________________________________________________________________________________

3. Structure & Composition

Display Module: Includes VGA LCD panel and backlight.
Touch Control Board: Capacitive touch sensing layer and corresponding control circuit.
Main Control Board: Responsible for core functions such as graphics processing and communication protocol parsing.
Housing: Metal or high-strength plastic housing with protection rating (e.g., IP20).

_____________________________________________________________________________________________________________

4. Application Areas

Industrial Automation: Used as an Operator Interface Panel for monitoring and control.
Process Control Systems: Applied in environments requiring real-time monitoring such as power plants and chemical factories.
SCADA Systems: Serves as a human-machine interaction terminal for upper computers.
Smart Devices: Modern intelligent equipment integrated with edge computing and IIoT.

_____________________________________________________________________________________________________________

5. Installation & Maintenance

Installation Guidelines

Location Selection: Should be installed in a dry, well-ventilated location away from direct strong light to ensure display effect.
Power Connection: Ensure the use of a stable DC power supply (usually 24VDC) and check the polarity.
Grounding: Due to the metal housing, proper grounding is recommended to prevent electromagnetic interference.

Maintenance Points

Environment Inspection: Regularly check the operating environment temperature and humidity to ensure they are within the rated range (0℃-50℃, humidity 10%-90%).
Cleaning & Maintenance: Wipe the screen gently with a soft, dry cloth. Avoid using corrosive cleaners to prevent damage to the capacitive touch layer.
Software & Hardware Inspection: Regularly check if the interface connections are firm, and confirm that the main control board and display are properly connected to avoid display abnormalities caused by looseness.

6. Related Models

eTOP30 is a specification in the UniOp series. Similar models include:

eTOP40/50: Models with larger sizes or different resolutions.
eTOP07: Another 7-inch touch screen model.

————————————————————————————————-
