Uniop ETOP12
1. Overview
The eTOP12 is a touch display specifically designed for industrial on-site applications, mainly used to replace traditional UniOP small-size panels (such as eTOP10). It has undergone significant upgrades in hardware performance, primarily targeting projects that require higher resolution display, more complex user interfaces, and stronger communication capabilities.
___________________________________________________________________________________________________________________________
2. Specifications & Product Features
|
Specifications
|
Specific Values
|
Remarks
|
|---|---|---|
|
Display Size
|
5.6 Inches
|
Medium size, suitable for visual operations in industrial sites
|
|
Resolution
|
800×480 Pixels
|
Higher display clarity compared to old panels
|
|
Color Depth
|
16-bit Color (65,536 Colors)
|
Supports richer graphics and animations
|
|
Touch Method
|
Resistive Touch
|
Traditional industrial standard with strong oil stain resistance
|
|
Communication Interfaces
|
3 Ports (depending on model)
|
Usually includes RJ45 Ethernet, RS-485, etc.
|
|
Operating Temperature
|
0°C to 45°C
|
Suitable for common industrial environments
|
|
Protection Level
|
IP65 (Front Panel)
|
Dustproof and waterproof, suitable for harsh environments
|
|
Power Consumption
|
600 mA @ 24 VDC
|
Stable power consumption, complying with industrial standards
|
___________________________________________________________________________________________________________________________
3. Structure & Composition
The eTOP12 adopts a modular design, mainly composed of the following parts:
- Display Unit: Includes a TFT color display and resistive touch glass.
- Main Control Board: Built-in Mitsubishi JMobile Runtime environment, responsible for running HMI programs.
- Front Panel: Usually made of tempered glass or high-strength plastic, equipped with status indicators.
- Connection Ports: The rear panel is equipped with various communication interfaces for easy connection to PLCs or upper computers.
___________________________________________________________________________________________________________________________
4. Application Fields
Due to its improved performance, the eTOP12 is widely used in scenarios requiring high graphic display and complex operations:
- Process Industry: Real-time monitoring in fields such as petroleum, chemical industry, and electric power.
- Manufacturing Industry: Process control and equipment status display of production lines.
- Building Automation: Human-computer interaction in large-scale facility management systems.
- Equipment Maintenance: Used as a device status indicator and alarm prompt terminal.
___________________________________________________________________________________________________________________________
5. Installation & Maintenance
Installation
The eTOP12 supports wall-mounted or embedded installation. Since its protection level is IP65, attention should be paid to the front panel sealing during installation to avoid water vapor infiltration.
Maintenance
The touch screen is resistive, and its surface is relatively easy to clean, making it suitable for industrial environments that require frequent cleaning. Routine inspections include: checking for loose interfaces, cleaning the touch screen surface, and replacing aging gaskets (if any).
Note: This product is designed for industrial use only. Please follow the installation and maintenance guidelines to ensure stable operation.
————————————————————————————————-
