UNIOP ETOP03-0046 Control Card Module

UNIOP ETOP03-0046

1. Basic Overview

UniOP ETOP03-0046 is an economical HMI product belonging to the UniOP ETOP series. Its main features include a compact size (3.8-inch screen), touch function support, and rich communication interfaces, making it suitable for installation in narrow spaces. It is usually used with other UniOP controllers (such as the ETOP20C series) as an on-site operation interface.

_____________________________________________________________________________________________________________

2. Key Technical Parameters

The following are the main technical specifications of this model (based on official UniOP technical data):

Display Screen: 3.8-inch TFT color LCD (approximately 240×320 pixel resolution)
Power Supply: 24V DC
Current Consumption: Approximately 200-300 mA (depending on display brightness and usage conditions)
Operating Temperature: 0°C to +50°C (some data indicates it may support a wider range)
Protection Level: IP65 (front panel protection level)
Communication Interfaces:

Storage: Built-in storage for running user programs
- CAN Bus: For connecting to PLCs (such as ETOP20C, ETOP310 series)
- RS485/RS232: For fieldbus communication
- USB Interface: For program downloading and USB device connection
- Ethernet: For network communication (not supported by some variants)

_____________________________________________________________________________________________________________

3. Product Features

High Durability: The front panel with IP65 protection level can effectively prevent dust and water, making it suitable for industrial on-site environments.
Easy Integration: As a member of the UniOP series, this panel has excellent compatibility with UniOP controllers and can be quickly integrated into UniOP’s programming software.
Low Power Consumption: Compared with large touch screens, ETOP03-0046 has lower power consumption, making it suitable for occasions sensitive to power consumption.
Human-Machine Interaction: Supports touch operation and basic graphic display, which can intuitively show device status and data.

_____________________________________________________________________________________________________________

4. Structure and Composition

Front Panel: Equipped with a touch screen and control buttons.
Rear Housing: Built-in electronic components (CPU, memory, power management, etc.).
Connection Terminals: For connecting power cables and communication cables (CAN, RS485, USB, etc.).
Installation Accessories: Including brackets or buckles for easy fixed installation.

_____________________________________________________________________________________________________________

5. Application Fields

Standalone Machine Monitoring: As an operation panel for standalone equipment (such as a single motor, pump).
On-Site Control: Installed on production lines, packaging machines, and conveyor equipment as the control center for on-site operators.
Small-Scale Machine Vision: Cooperates with small sensors or PLCs to realize a simple machine vision interface.
Teaching and Training: Due to its easy programming and use, it is often used for industrial automation teaching demonstrations.

————————————————————————————————-
