Type:Precision Linear Actuator

Series:LSDH4

Model😛

Load Capacity:Up to 50 kg

Travel Range:Up to 1,000 mm

Actuation Speed:0.1 to 1,000 mm/s

Backlash:< 0.1 mm

Repeatability:±0.02 mm

Operating Temperature:-20°C to 80°C

Input Voltage:24 V DC

Current Consumption:Max. 2 A

Shaft Diameter:φ12 mm

Connector Type:Standard Socket Connector

    The THK LSDH4-P boasts an advanced motor design that combines high efficiency with exceptional durability, making it suitable for continuous high-speed operation in harsh industrial environments. Its integrated heat sink ensures optimal thermal management, reducing the risk of overheating during prolonged use.

    This precision linear motion control module supports EtherCAT communication protocol, enabling seamless integration with a wide range of automation systems. This feature facilitates real-time data exchange, improving system responsiveness and overall productivity.

    With a resolution of 0.1 μm, the THK LSDH4-P delivers unparalleled accuracy in positioning tasks. Whether in the assembly line or in complex manufacturing processes, this module ensures that each movement is precisely controlled, minimizing errors and maximizing quality.

    Equipped with a robust aluminum alloy construction, the THK LSDH4-P is designed to withstand the rigors of industrial applications. The use of high-grade materials ensures that the module maintains its performance over extended periods, even under heavy loads.

    The module comes with an incremental encoder that provides reliable feedback on the position and velocity of the moving parts. This encoder integration allows for accurate monitoring and adjustment, enhancing the precision of the motion control system. Additionally, the THK LSDH4-P offers a wide speed range, from low to high speeds, providing flexibility for various application scenarios.
