Frequency Range:1 MHz to 20 MHz

Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Arbitrary

Output Amplitude:20 mVpp to 10 Vpp

Resolution:14-bit

Sampling Rate:100 MSa/s

Memory Depth:16 kSa

Interface:USB, Ethernet, GPIB

    The Tektronix 5B42 Arbitrary Function Generator is an essential tool for engineers and technicians working in the field of industrial control systems. This versatile generator supports a wide range of waveforms including sine, square, triangle, ramp, pulse, and arbitrary functions. With its high-resolution output and extensive frequency range, it ensures precise and reliable signal generation for testing and development purposes. Designed with user convenience in mind, the 5B42 comes equipped with intuitive navigation keys and programmable function keys for easy operation. Its compact form factor makes it suitable for space-constrained environments, while still delivering robust performance. The generator supports multiple communication interfaces, including Ethernet (Modbus/TCP), RS-485 (Modbus/RTU), and open networks like PROFIBUS-DP, CC-Link, and DeviceNet, facilitating seamless integration into existing systems. Additionally, the 5B42 adheres to stringent reliability standards, meeting RoHS and WEEE compliance, ensuring environmental safety and long-term durability.
