Frequency Range:9 kHz to 2.1 GHz

Output Power:-127 dBm to +13 dBm

Phase Noise:< -100 dBc/Hz at 10 kHz offset

Spectral Purity:Typically < -100 dBc for spurious signals

Resolution:0.1 Hz frequency resolution

Interface:Ethernet, USB, GPIB

Power Supply:100-240V AC, 50/60 Hz

    The Tektronix 5440 Arbitrary Waveform Generator is designed to meet the demanding requirements of modern electronics testing and development. Its dual-channel capability allows for versatile signal generation, making it ideal for applications such as RF communication, automotive electronics, and semiconductor testing.

    This high-precision signal source boasts a broad frequency range from 0.01 Hz to 30 MHz, ensuring accurate and reliable waveform generation across a wide spectrum. With 14-bit resolution and a sampling rate of 100 MSa/s, the Tektronix 5440 delivers crisp and clear signals, enabling engineers to test and validate their designs with confidence.

    The device supports a variety of waveform types including arbitrary, sine, square, triangle, pulse, ramp, and noise, providing unparalleled flexibility for diverse testing scenarios. The generous memory depth of 16 kpts allows for extensive waveform storage and manipulation, further enhancing its utility.

    Connectivity options are plentiful, featuring USB, LAN, GPIB, and RS-232 interfaces for seamless integration with existing systems and networks. The user-friendly interface ensures ease of use, allowing users to quickly configure and generate the desired signals without the need for complex setups.

    With its robust design and exceptional performance, the Tektronix 5440 Arbitrary Waveform Generator is a must-have tool for any electronics testing lab or research facility.
