Series:CQ2

Model:CQ2B40TF-25DCMZ

Bore Size:40 mm

Stroke Length:25 mm

Actuation Type:Double-acting

Maximum Operating Pressure:10 bar

Port Thread Type:M5 x 0.8

Mounting Style:Direct mounting

Material:Aluminum alloy

Weight:0.2 kg

Operating Temperature Range:-20°C to +60°C

Cushioning Type:Rubber bumper

    The SMC Pneumatic Cylinder CQ2B40TF-25DCMZ is engineered for demanding industrial environments where precision and reliability are paramount. Its compact yet robust design ensures smooth operation in a variety of applications.

    Featuring a high-pressure rating of 7MPa, this cylinder can handle tough conditions without compromising on performance. The aluminum body is lightweight yet durable, providing excellent strength-to-weight ratio.

    With its double-acting mechanism, the CQ2B40TF-25DCMZ offers precise control over force and position, making it suitable for tasks requiring both pushing and pulling capabilities. The use of NBR rubber seals ensures long-lasting durability and leakage resistance.

    For easy integration into existing systems, the cylinder utilizes a standard 1/2″ NPT port connection, compatible with a wide range of fittings. The bolted end mounting style facilitates quick assembly and disassembly.

    To further enhance its operational efficiency, the cylinder incorporates an oil-impregnated steel piston ring for cushioning, reducing wear and ensuring smooth, silent operation. This feature is particularly beneficial in noise-sensitive applications.
