Type:Analog Input Module

Model Number:6ES7 231-0HC22-0XA8

Category:SIMATIC S7-1500

Channels:4

Supply Voltage:DC 5 V

Signal Range:0…10 V DC

Resolution:12-bit

Accuracy:+/- 0.1%

Input Filter:Configurable

Operating Temperature:-25°C to +60°C

Humidity:5% to 95% non-condensing

Dimensions:122mm x 90mm x 94mm

Weight:0.32kg

    Precision engineered for seamless integration into the SIMATIC S7-200 PLC system, the 6ES7 231-0HC22-0XA8 Analog Input Module ensures reliable and accurate data acquisition for your industrial operations.

    Featuring an impressive array of 8 analog inputs, this module is designed to handle a wide range of signals, from voltage to current, ensuring flexibility across various industrial applications.

    With support for a broad signal range of 0-10V DC and current range up to 0..20 mA, it caters to diverse measurement requirements, enhancing its utility in complex systems.

    Equipped with a 12/11-bit converter, this module offers high-resolution readings, delivering precise data acquisition capabilities essential for optimal control and monitoring.

    Built to withstand harsh industrial conditions, the module operates within a temperature range of -25°C to +60°C and maintains functionality under varying humidity levels without condensation, ensuring durability and longevity.

    The inclusion of RS-485 and DeviceNet connectivity options facilitates easy integration with other devices, enhancing system interoperability and efficiency.
