CPU Type:Compact

Operating Range:4-24 VDC

Memory Capacity:32 KB Work Memory

Input/Output Count:16 Digital Inputs (DI) + 16 Digital Outputs (DO)

Analog Inputs:4

Analog Outputs:1

Power Supply:Integrated 24 VDC

Communication Interfaces:MPI Interface

Programming Languages:Ladder Diagram, Function Block Diagram, Structured Text

    Unleash the full potential of your industrial automation system with the Siemens S7-300 CPU 314 Compact IF Module. This compact yet powerful module is specifically designed to enhance operational efficiency, offering an integrated suite of digital and analog I/O channels.

    Featuring a robust 24V DC power supply, it ensures reliable operation under various industrial conditions, supporting a wide temperature range from -25°C to +60°C for stable performance throughout the year.

    With its comprehensive set of 16 digital inputs (DI) and 16 digital outputs (DO), the module enables precise control over machinery and processes, while its 4 analog inputs (AI) and 1 analog output (AO) facilitate the integration of sensors and actuators for enhanced data acquisition and actuation.

    The built-in MPI interface allows for seamless communication with other Siemens devices, creating a cohesive and efficient networked environment. Its 32KByte working memory ensures ample space for storing programs and data, enabling advanced automation tasks without the need for external storage.

    Engineered for long-term reliability, this module boasts an extended storage temperature range from -40°C to +85°C, making it suitable for demanding environments. Its compact dimensions (110mm x 105mm x 120mm) allow for easy installation in even the most space-constrained applications.
