Display Size:12.1″ WVGA

Resolution:800×480 pixels

Operating System:Windows Embedded Standard 7

CPU:Intel Atom processor

RAM:1 GB DDR3

Flash Memory:8 GB

Touch Screen:Multi-touch

Communication Interface:Profinet, Ethernet, USB, RS232

Power Supply:DC 24V

Operating Temperature:-10°C to +50°C

Dimensions:302 mm x 201 mm x 44 mm

Weight:Approx. 1.2 kg

    The Siemens 6AV6 545-0DA10-0AX0 Multi Panel offers an intuitive and responsive touch screen interface, ensuring easy navigation and operation. Its robust design withstands harsh industrial environments, guaranteeing reliable performance under varying conditions.

    Equipped with a powerful processor and ample memory, this panel ensures smooth operation even during demanding tasks. The integrated SIMOTION control software streamlines the setup and programming process, allowing for efficient customization to meet specific application needs.

    With support for multiple connectivity options, including Ethernet, USB, and RS-232, the Multi Panel facilitates seamless integration with other industrial devices and systems. This enhances workflow efficiency and interoperability within the production line or plant.

    Designed with a wide operating temperature range, from -20°C to 55°C, the panel can function reliably in cold storage areas or hot manufacturing environments. Additionally, its ability to withstand storage temperatures from -40°C to 70°C ensures it remains operational throughout transportation and installation processes.

    In terms of dimensions, the Siemens 6AV6 545-0DA10-0AX0 measures 345 x 246 x 70 mm, making it compact yet powerful enough to fit into tight spaces on the factory floor. Its weight of 2.2 kg ensures ease of handling during installation and relocation.
